| 1. |
700109753
|
[2] |
BEARING ASSY,97 mm ID x 108 mm OD x 33 mm
|
CAS
BEARING ASSEMBLY - flange
|
| 2. |
700107962
|
[2] |
STRAP
|
HFI
- brace Superseded by part number: 700131945
|
| 3. |
50468
|
[2] |
SPHERICAL BEARING,38.1 mm ID x 80 mm OD x 22, 43.66 mm
|
IH
- spherical
|
| 4. |
50575
|
[4] |
FLANGE
|
NNA
- bearing Superseded by part number: 663562R1
|
| 5. |
700107965
|
[1] |
SUPPORT
|
HFI
- roller, left (S.N. CFH0016501 thru CFH0017638)
|
| . . |
700122714
|
[1] |
SUPPORT
|
HFI
- roller, left (S.N. CFH0017639 and on) Superseded by part number: 700131959
|
| 6. |
700100054
|
[4] |
SPACER
|
CAS
|
| 7. |
700118654
|
[2] |
SHIM
|
CAS
|
| 8. |
700118652
|
[2] |
WASHER
|
CAS
- wear
|
| 9. |
700118649
|
[1] |
ROLLER
|
HFI
ASSEMBLY - track, Includes: Ref. 11 and 12
|
| 10. |
700116219
|
[2] |
SPROCKET ASSY.
|
HFI
RIENK - track
|
| 11. |
700118651
|
[1] |
SHAFT
|
HFI
- roller, track
|
| 12. |
8050825
|
[4] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
- cylindrical Superseded by part number: F82059
|
| 13. |
700114407
|
[2] |
CRANK
|
IH
ROD - guide Superseded by part number: 700133284
|
| 14. |
700116120
|
[1] |
SUPPORT
|
HFI
- roller, right (S.N. CFH0016501 thru CFH0017638)
|
| . . |
700122715
|
[1] |
SUPPORT
|
HFI
- roller, right (S.N. CFH0017639 and on)
|
| 15. |
700110467
|
[1] |
BEARING ASSY,44.45 mm ID x 92.44 mm OD x 29 mm
|
L
BEARING ASSEMBLY - flange
|
| 16. |
700107960
|
[2] |
OIL SEAL
|
CAS
RING - grass (S.N. CFH0016501 thru CFH0017638) Superseded by part number: 700122771
|
| . . |
700122771
|
[2] |
SPACER
|
IH
RING - grass (S.N. CFH0017639 and on)
|
| 17. |
700707164
|
[1] |
ROLLER
|
HFI
rubber
|
| 18. |
712158
|
[1] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
BEARING - spherical Superseded by part number: 47577203
|
| 19. |
51318
|
[1] |
BEARING
|
IH
- spherical Superseded by part number: 668718R92, 47577169
|
| . . |
703959
|
[4] |
BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd
|
CAS
1/2-13 x 1 C
|
| . . |
700013
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
7700065
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 x 3/4 RHSNB Superseded by part number: 280430
|
| . . |
700047
|
[3] |
BOLT
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
700054
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
3/8-16 x 1-1/4 RHSNB Superseded by part number: 86508773
|
| . . |
7700131
|
[8] |
SHROUD,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 x 1 RHSNB Superseded by part number: 433-816, 433-816, NLS
|
| . . |
68619
|
[8] |
BOLT,Round, 1/2" - 13 x 1 1/4", Grade 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| . . |
768226
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 x 1-3/4 RHSNB Superseded by part number: 88530
|
