纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (04-11) - HARNESS, REAR WIRE HARNESS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
684 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87647731 | [1] | WIRE HARNESS | BURHARNESS, Valves |
| 2. | L18331 | [1] | CABLE TIE,375.9mm L | CAS Superseded by part number: 529070 |
| 6. | 201-119 | [1] | FITTING | CAS1/4 ORFS x 1/2 ORB; Incl. Ref 7, 8 |
| 7. | 238-6011 | [1] | O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 9825770 |
| 8. | 237-6008 | [1] | O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro | CASBoss end Superseded by part number: 128825 |
| 10. | 201-421 | [1] | TEE,9/16"-18 ORFS x 9/16"-18 Sw Run | CASAt Tandem Pump; Incl. Ref 11 |
| 12. | 87403648 | [1] | PRESSURE SWITCH | BURCharge; At Tee On Tandem Pump |
| 13. | 86982400 | [1] | SPACER | NH |
