凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (088) - TAILGATE LATCH ASSEMBLY, SERIAL NUMBER CFH0016839 AND ON Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
914 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700119106
|
[1] |
LATCH
|
CAS
- left
|
| 2. |
763870
|
[2] |
CLEVIS PIN
|
CAS
5/8 x 4 clevis pin
|
| 3. |
700119111
|
[1] |
LATCH
|
CAS
- strap, left
|
| 4. |
700115939
|
[2] |
PIN
|
HFI
|
| 5. |
51200241
|
[2] |
SPACER
|
CAS
|
| 6. |
700115920
|
[2] |
LINK
|
CAS
|
| 7. |
488122
|
[2] |
SPACER
|
HFI
|
| 8. |
700115941
|
[4] |
LINK
|
CAS
|
| 9. |
700119093
|
[1] |
SUPPORT
|
HFI
LINK - stop
|
| 10. |
700115929
|
[2] |
PIN
|
CAS
|
| 11. |
700119108
|
[1] |
LATCH
|
CAS
- right
|
| 12. |
76612
|
[1] |
WASHER
|
HFI
3/4 x 10 GAUGE MACHINERY BUSHING
|
| 13. |
700109079
|
[2] |
SPACER
|
HFI
|
| 14. |
700119112
|
[1] |
LATCH
|
CAS
- strap, right
|
| 15. |
700115918
|
[2] |
PIN
|
CAS
|
| 16. |
700115942
|
[4] |
PLATE
|
HFI
|
| 17. |
6287155
|
[4] |
SPACER
|
HFI
|
| 18. |
758441
|
[2] |
SPRING
|
IH
- tension
|
| 19. |
700119092
|
[1] |
SUPPORT
|
HFI
- left
|
| 20. |
700116130
|
[1] |
SUPPORT
|
HFI
- switch
|
| 21. |
700707978
|
[1] |
SPRING
|
IH
- compression
|
| 22. |
763557
|
[1] |
PIN
|
CAS
3/8 x 2-3/4 clevis pin Superseded by part number: Q657
|
| 23. |
700116058
|
[1] |
LINK
|
HFI
- stop
|
| . . |
703249
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
873406
|
[2] |
BOLT,Hex, 1/2" - 13 x 3", Gr 5, Full Thd
|
CAS
1/2-13 x 3 FTC Superseded by part number: 113-420
|
| . . |
7700156
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 x 1-1/2 RHSHB Superseded by part number: 280420
|
| . . |
704635
|
[1] |
NUT
|
CAS
3/8-16 HCLN Superseded by part number: 230-4216, 230-4216, 88902
|
