| 1. |
700114351
|
[2] |
SUPPORT
|
HFI
- tailgate
|
| 2. |
700114353
|
[1] |
SUPPORT
|
HFI
- center
|
| 3. |
700114321
|
[1] |
SIDE ASSY.
|
HFI
SIDE - tailgate, left Superseded by part number: 700124620
|
| 4. |
771808
|
[2] |
HEX SOC SCREW,Flat Hd, 3/8" - 16 x 1 1/4"
|
CAS
3/8-16 x 1-1/4 HSFCHCS Superseded by part number: 61-43820
|
| 5. |
700707981
|
[2] |
SCREW,FLAT, 3/4" - 10 x 1-3/4"
|
L
3/4-10 x 1-3/4 HSFCHCS
|
| 6. |
700100927
|
[6] |
HUB
|
L
- roller
|
| 7. |
8050825
|
[6] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
- cylindrical Superseded by part number: F82059
|
| 8. |
700114379
|
[1] |
ROLLER ASSY.
|
HFI
ROLLER ASSEMBLY - lower Superseded by part number: 700130853
|
| 9. |
700114384
|
[1] |
ROLLER ASSY.
|
HFI
ROLLER ASSEMBLY - flanged Superseded by part number: 700125801
|
| 10. |
700119682
|
[1] |
SHAFT
|
HFI
- roller, flanged
|
| 11. |
586156R92
|
[2] |
BEARING, ROLLER, CYL,0.7505" ID x 47 mm OD x 0.8437, 0.53125"
|
IH
BEARING - cylindrical, sealed Superseded by part number: 76802
|
| 12. |
700122470
|
[1] |
SUPPORT
|
CAS
- tie, lower
|
| 13. |
6467674
|
[2] |
SPACER
|
CAS
|
| 14. |
700114323
|
[1] |
SIDE ASSY.
|
HFI
SIDE - tailgate, right Superseded by part number: 700124621
|
| 15. |
700116170
|
[2] |
ROLLER
|
CAS
- rear Superseded by part number: 700124612
|
| . . |
702035
|
[4] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 x 1-1/4 C
|
| . . |
7701196
|
[4] |
BOLT,Hex, 3/4" - 10 x 1 3/4", Gr 5
|
CAS
3/4-10 x 1-3/4 C Superseded by part number: 88725
|
| . . |
7883374
|
[18] |
SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 x 3/4 HWHMS Superseded by part number: 255918
|
| . . |
7883382
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 x 1 HWHMS Superseded by part number: 87034804
|
| . . |
704734
|
[26] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN Superseded by part number: 86521609
|
