凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (092) - EJECTOR KICKER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
144 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700708068
|
[2] |
CLEVIS PIN,15.77mm OD x 68.66mm L
|
IH
5/8 x 2-1/2 CLEVIS PIN
|
| 2. |
700115945
|
[1] |
STRUT
|
HFI
- kicker, left
|
| 3. |
700115944
|
[1] |
PIPE
|
HFI
- cross
|
| 4. |
763227
|
[2] |
BRACKET
|
CAS
5/8 x 3 CLEVIS PIN Superseded by part number: 51200161, 51200161, NLS
|
| 5. |
77032
|
[2] |
FITTING
|
CAS
1/4-28 ZERK Superseded by part number: 88775
|
| 6. |
700122576
|
[1] |
STRUT
|
CAS
- kicker, right
|
| 7. |
700115943
|
[2] |
TUBE,25.4 mm OD, 61 mm Length
|
CAS
BUSHING
|
| 8. |
700122757
|
[1] |
SUPPORT
|
HFI
- actuator Superseded by part number: 700122729
|
| 9. |
700710188
|
[2] |
SCREW
|
CAS
NO. 6-32 x 3/4 CRPHMS - stainless steel
|
| 10. |
700710189
|
[2] |
LOCK NUT
|
CAS
NO. 6-32 x 3/4 LHSN - stainless steel
|
| 11. |
700710187
|
[2] |
WASHER
|
CAS
NO. 6 P STAINLESS STEEL
|
| . . |
7706768
|
[2] |
5/16-18 x 1-1/4 C
|
DRIVE BUSHING,38.25mm ID x 47.74mm OD x 36.1mm L
|
| . . |
7701600
|
[6] |
BOLT,Hex, 1/2" - 13 x 3 3/4", Gr 5
|
CAS
1/2-13 x 3-3/4 C Superseded by part number: 86505992
|
| . . |
704619
|
[2] |
SUPPORT
|
NNA
5/16-18 HCLN Superseded by part number: 230-4215
|
| . . |
704288
|
[4] |
LOCK NUT
|
CAS
1/2-13 HCLN Superseded by part number: 230-4218
|
| . . |
495-11066
|
[2] |
WASHER,5/8", SAE
|
CAS
5/8 NP Superseded by part number: 87365
|
