神钢零件查询(FD6(T)14) - NISSAN DIESEL ENGINE ASN 050001 - LK400 & LK500A (1/06-12/06) (06-010) - FAN "BOLT" Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
598 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VG0112100074 | [4] | SPECIAL WASHER | KOBBOLT,W/WASHER,FOR A1 ONLY |
| 1. | VG0812109510 | [4] | BOLT BOLT,FOR A2 ONLY | BOLT BOLT,FOR A2 ONLY |
| 1. | VG0812104028 | [4] | BOLTS BOLT,W/WASHER,FOR A3 ONLY | BOLTS BOLT,W/WASHER,FOR A3 ONLY |
| 1. | VG0112100044 | [4] | BOLT BOLT,W/WASHER,FOR A4 ONLY | BOLT BOLT,W/WASHER,FOR A4 ONLY |
| 1. | VG0112100124 | [4] | BOLT BOLT,W/WASHER,FOR A5 ONLY | BOLT BOLT,W/WASHER,FOR A5 ONLY |
| 1. | VG0812106510 | [4] | BOLT,FOR A6 ONLY | |
| 1. | VG0812104528 | [4] | BOLT,W/WASHER,FOR A7 ONLY | |
| 2. | VG0891514010 | [4] | WASHER WASHER-SPRING,FOR A2,A6 ONLY | WASHER WASHER-SPRING,FOR A2,A6 ONLY |
