| 1. |
84544474
|
[1] |
ROLL
|
NH
|
| 2. |
86590752
|
[1] |
BEARING ASSY
|
NH
Superseded by part number: 87660333
|
| 3. |
86609558
|
[1] |
BEARING ASSY,45mm ID
|
NH
|
| 4. |
87392936
|
[1] |
ROLLER ASSY.
|
PA
Floor
|
| 5. |
86602143
|
[2] |
WEAR PLATE
|
NH
|
| 6. |
87027838
|
[1] |
BEARING ASSY
|
PA
|
| 7. |
87384472
|
[2] |
COLLAR
|
PA
Superseded by part number: 563733
|
| 8. |
86837676
|
[2] |
FLANGED BEARING
|
PA
Superseded by part number: 86979948
|
| 9. |
84405072
|
[1] |
ROLL
|
NH
Starter
|
| 10. |
84483109
|
[2] |
PIVOT PLATE
|
NH
|
| 11. |
133941
|
[1] |
BALL BEARING,44.45mm ID x 84.99mm OD x 22mm W
|
NH
Superseded by part number: 84330073
|
| 12. |
86548973
|
[2] |
FLANGE
|
NH
Superseded by part number: 86620027
|
| 13. |
52443
|
[1] |
BALL BEARING,38.1mm ID x 79.99mm OD x 22mm W
|
NH
Superseded by part number: 664073R92
|
| 14. |
52444
|
[1] |
COLLAR,38.2mm ID x 60.33mm OD x 18.3mm Thk
|
NH
Superseded by part number: 47577185
|
| 15. |
47582850
|
[1] |
SHIELD
|
PLO
RH
|
| 16. |
47596887
|
[1] |
PLATE
|
NH
LH, Incl 35
|
| 17. |
86506990
|
[2] |
HALF-DISC
|
PA
Superseded by part number: 86637198
|
| 18. |
45631
|
[1] |
COLLAR
|
NH
Superseded by part number: 47577169
|
| 19. |
9804272
|
[4] |
BOLT,Hex, M16 x 50mm, Cl 8.8, Full Thd
|
NH
|
| 20. |
9804268
|
[4] |
BOLT,Hex, M12 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 21. |
9671487
|
[8] |
BOLT,Hex, M12 x 50mm, Cl 8.8
|
PA
|
| 22. |
9670066
|
[8] |
FLANGE BOLT,Hex, M12 x 30mm, Cl 8.8
|
NH
|
| 23. |
47536123
|
[2] |
SHIELD
|
PLO
RH
|
| 24. |
9671714
|
[2] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 25. |
86531147
|
[4] |
BOLT,Hex, M10 x 16mm, Cl 8.8, Full Thd
|
NH
|
| 26. |
86050286
|
[4] |
FLANGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 27. |
48564
|
[1] |
90 ELBOW,90 Degree, 11/16" x 5/8", 1/8" NPT
|
NH
|
| 28. |
86580291
|
[1] |
ADAPTER,1/8" - 27 x 1/4" - 28
|
NH
|
| 29. |
87016
|
[1] |
WASHER,0.41" ID x 0.81" OD x 0.07" Thk
|
NH
|
| 30. |
86629566
|
[1] |
PLASTIC-RUBBER TUBE,2.8mm ID x 4.8mm OD
|
A
Superseded by part number: 87014413
|
| 33. |
9804278
|
[1] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 34. |
9804261
|
[3] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 35. |
47377884
|
[1] |
WARNING DECAL
|
NH
|
