凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (62.140.AJ[03]) - LH DRIVE - CHAIN Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
670 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86549269
|
[2] |
CHAIN,RC80, 64 Links x 25.4mm = 1625.6mm
|
PA
Incl 10
|
| 2. |
47531223
|
[1] |
CHAIN,RC80HFP, 158 Links x 25.4mm = 4013.2mm L
|
NH
Incl 14
|
| 3. |
9804061
|
[1] |
CHAIN,80, 84 Links x 25.4mm = 2133.6mm
|
NH
Incl 10
|
| 4. |
84271552
|
[2] |
IDLER,50.8mm OD x 56mm L
|
NH
|
| 5. |
84266904
|
[1] |
PLATE
|
NH
|
| 6. |
80700
|
[2] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 7. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 9. |
86508581
|
[2] |
BOLT,Hex, M12 x 90mm, Cl 8.8
|
NH
|
| 10. |
84356440
|
[2] |
LINK,25.4mm Pitch
|
NH
Incl in 1, 3
|
| 11. |
84597734
|
[1] |
CHAIN,60H-2, 69 Links x 19.05mm = 1314.45mm L
|
NH
Incl 12, 13
|
| 12. |
84605997
|
[1] |
LINK,RC60H-2, 19.1mm Pitch
|
NH
Master
|
| 13. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Offset Link, Incl in 11
|
| 14. |
47531224
|
[1] |
CHAIN
|
NH
Master Link, Incl in 2
|
