| 1. | 87311632 | [1] | HYDRAULIC VALVE | BURThree Spool; See Figure 08-18 Superseded by part number: 84355767 |
| 1. | 87311631 | [1] | HYDRAULIC VALVE | BURFour Spool; See Figure 08-18 Superseded by part number: 84355783 |
| 2. | 201-139 | [4] | HYD CONNECTOR,11/16"-16 ORFS x 7/8"-14 ORB | CASIncl. Ref 3, 4 Superseded by part number: 86615560 |
| 3. | 237-6010 | [1] | O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro | CASBoss End Superseded by part number: 72186125, 167269 |
| 4. | 238-6012 | [1] | O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 9993141 |
| 5. | 433796A1 | [1] | HOSE ASSY. | BUR1930 mm (76 in); Tilt; Right-Hand |
| 6. | 433797A1 | [1] | HOSE ASSY. | BUR1810 mm (71-5/16 in); Tilt; Left-Hand |
| 7. | 433798A1 | [1] | HOSE ASSY. | BUR1880 mm (74-1/16 in); Angle; Right-Hand |
| 8. | 433799A1 | [1] | HOSE ASSY. | BUR1885 mm (74-1/4 in); Angle; Left-Hand |
| 9. | 242999A1 | [3] | CLAMP | CAS |
| 10. | 811-12070 | [1] | CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 70mm, Cl 8.8 | CAS Superseded by part number: 338263 |
| 11. | 832-10412 | [4] | NUT,M12 x 1.75, Cl 8 | CAS Superseded by part number: 87780366, 412126 |
| 12. | L71188 | [2] | CLAMP,15.75mm ID, 13.46mm Bolt Hole, P Type | CAS |
| 13. | 994-12021 | [1] | SPACER,3/4" Tube x .840" | BRR |
| 14. | 201-121 | [2] | HYD CONNECTOR,13/16"-16, Blkhd, ORFS | IHIncludes Ref 15 |
| 15. | 238-6014 | [2] | O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro | CAS Superseded by part number: 9992298 |
| 16. | 201-423 | [2] | TEE,9/16"-18, Blkhd, Run, ORFS | CASIncl. Ref 17 |
| 18. | 201-903 | [6] | TUBE NUT,Blkhd, 13/16"-16 | CAS |
| 19. | 201-301 | [2] | ELBOW,90º, 13/16"-16, Blkhd, ORFS | CASIncl Ref 25 |
| 20. | 515-24206 | [2] | CLAMP,13/16", Insul, 7/16" Bolt | BRR Superseded by part number: 87530629 |
| 21. | 811-12035 | [2] | CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 35mm, Cl 8.8 | CAS Superseded by part number: 87035385 |
| 22. | 832-10410 | [1] | NUT,M10 x 1.5, Cl 8 | CAS Superseded by part number: 190003888452 |
| 23. | 436894A1 | [1] | BRACKET, SUPPORTING | BUR |
| 24. | 614-12025 | [1] | BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8, Full Thd | IH Superseded by part number: 300388 |
| 26. | 811-10035 | [1] | CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 35mm, Cl 8.8 | BUR Superseded by part number: 707700560 |
| 27. | 811-12055 | [1] | CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 55mm, Cl 8.8 | CAS Superseded by part number: 87033290 |
| 28. | 87704194 | [1] | HOSE ASSY. | BURHOSE ASSY., Angle Crossover, 1139 mm (44 7/8 in); Connects to Ref 7 |
| 29. | 87704195 | [1] | HOSE ASSY. | BURHOSE ASSY., Angle Crossover, 1232 mm (48 9/16 in); Connects to Ref 8 |
| 30. | 87429174 | [4] | STRAP | CAS Superseded by part number: 529070 |
| 31. | 87429172 | [4] | STRAP | CAS Superseded by part number: 529070 |
| 32. | 87310535 | [1] | SLEEVE | BUR200 mm |
| 33. | 87429176 | [2] | STRAP | CAS Superseded by part number: 529070 |
| 34. | 87429175 | [2] | STRAP | CAS Superseded by part number: 529070 |
