| 1. | 87615547 | [2] | CYLINDER ASSY. | BURCYLINDER ASSY., 89 ID x 396 mm Stroke; Angle; See Figure 08-13; No Longer Availabe, Order 84135898 Angle Cylinder Assy., Ref 1A Superseded by part number: 84135900 |
| 1. | 84135900R | [2] | REMAN-HYD CYLINDER | BURReman for New PN 87615547 |
| 1. | 84135900C | [2] | CORE-HYD CYLINDER | BURReturn Number |
| 1A. | 84135898 | [2] | HYDRAULIC CYLINDER | BURCYLINDER ASSY., 89 ID x 396 mm Stroke; Angle; Not Illustrated; See Figure 08-13A Superseded by part number: 84135900 |
| 2. | 201-112 | [2] | HYD CONNECTOR,13/16"-16 ORFS x 7/8"-14 ORB | CASIncludes Ref. 3, 4 Superseded by part number: 73338799 |
| 3. | 237-6010 | [1] | O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro | CASBoss End Superseded by part number: 72186125, 167269 |
| 4. | 238-6014 | [1] | O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 9992298 |
| 5. | 201-326 | [2] | ELBOW,90º, 13/16"-16 x 7/8"-14, Adj, ORFS | CASIncl. Ref 6, 7 Superseded by part number: 85802961 |
| 8. | 87309486 | [2] | HOSE ASSY.,12.7mm ID x 1460mm L | BUR1460 mm (57-1/2 in); To Rod End Of Cylinder |
| 9. | 87309487 | [2] | HOSE ASSY.,12.7mm ID x 975mm L | BUR975 mm (38-7/16 in); To Closed End Of Cylinder |
| 10. | 445338A1 | [2] | HOSE PROTECTION,46.00 mm ID x 825.00 mm | BUR |
| 12. | L18331 | [2] | CABLE TIE,375.9mm L | CAS15" Superseded by part number: 529070 |
| 13. | 827-10040 | [2] | BOLT,Hex, M10 x 1.5 x 40mm, Cl 10.9, Full Thd | CAS Superseded by part number: 43248 |
| 14. | 827-10070 | [2] | BOLT,Hex, M10 x 1.5 x 70mm, Cl 10.9 | CAS Superseded by part number: 355788 |
| 15. | 892-11010 | [4] | LOCK WASHER,M10 | CAS Superseded by part number: 140028 |
| 16. | 435511A1 | [3] | PLATE | BUR |
| 17. | 436110A1 | [4] | SPACER | BUR |
| 18. | 436109A1 | [2] | SPACER | BUR |
| 19. | L74161 | [2] | HOSE,3.56mm ID x 533.4mm L, SAE 100R7 | CAS533 mm (21 in); Incl. Ref 21 |
| 20. | L54694 | [2] | HOSE | CASGrease, 1041 mm (41 in); Incl. Ref 21 Superseded by part number: 87414, R45862 |
| 21. | 219-8 | [1] | LUBE NIPPLE,1/4"-28 x 1/2" | CAS Superseded by part number: 87414 |
| 22. | F53473 | [4] | LOCK NUT,1/8-27 NPSM | CAS1/8 PT Superseded by part number: 76085536 |
| 23. | 87434550 | [2] | COVER ASSY | BUR |
| 24. | 627-10035 | [2] | BOLT,Hex, M10 x 1.5 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 86624978 |
| 25. | 895-15010 | [2] | WASHER,M11 x 24 x 2 | CAS Superseded by part number: 86625253 |
| 26. | 309096A1 | [2] | SQUARE NUT | CASM10 Superseded by part number: 229197A1 |
| 27. | 827-10090 | [2] | BOLT,Hex, M10 x 1.5 x 90mm, Cl 10.9 | CAS Superseded by part number: 828-10090 |
| 29. | 446431A1 | [1] | SPACER | BUR |
| 30. | 832-10410 | [2] | NUT,M10 x 1.5, Cl 8 | CAS Superseded by part number: 190003888452 |
