纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (08-21) - SECTION ASSEMBLY - TILT, ANGLE, AND AUXILIARY New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
364 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 87402657 | [1] | HYD VALVE SECTION | BURTilt; Incl. Ref 1 - 6, 8, 9 - 16 |
| . . | 87402658 | [1] | HYD VALVE SECTION | BURAngle; Incl. Ref 1 - 6, 7A, 9 - 16 |
| . . | 87402659 | [1] | HYD VALVE SECTION | BURAuxiliary/Ripper; Incl. Ref 1 - 6, 7, 9 - 16 |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONHousing |
| 3. | H267591 | [2] | SPRING SEAT | CAS Superseded by part number: 527294 |
| 4. | 100854A1 | [1] | SPRING | CAS |
| 5. | N14593 | [1] | STEP BOLT | CAS |
| 6. | S301092 | [1] | FLANGE COVER CAP | CAS |
| 7. | N8950 | [2] | VALVE | CASRelief Valve; Auxiliary/Ripper Section; See Figure 08-23 |
| 7A. | 122119A1 | [2] | KIT | CASAnti-Cavitation Valve; Angle Section; See Figure 08-22 |
| 8. | D87307 | [2] | VALVE | CASLoad Check Valve; Tilt Section; See Figure 08-22 Superseded by part number: 274858 |
| . . | 352796A1 | [1] | PACKAGE | CASRepair Kit; Incl. Ref 9 - 16 |
| 9. | 357164A1 | [1] | BOOT | CAS |
| 10. | 357163A1 | [1] | RETAINER | CAS |
| 11. | N8194 | [1] | LARGE PLATE | CASPLATE, LARGE |
| 12. | 61-3258 | [2] | HEX SOC SCREW,1/4"-20 x 1/2" | CAS Superseded by part number: 81960 |
| 13. | D88730 | [2] | WASHER,0.77" ID x 1.43" OD | CAS |
| 14. | D88729 | [2] | WASHER,0.76" ID x 1" OD x 0.05" Thk | CAS |
| 15. | 9706714 | [2] | O-RING,0.139" Thk x 0.734" ID, -210, Cl 5, 75 Duro | WIN |
| 16. | 102201A1 | [2] | HEX SOC SCREW,1/4" - 20 x 7/8", W/ Nylon Patch | CAS |
