神钢零件查询(FD6(T)14) - NISSAN DIESEL ENGINE ASN 050001 - LK400 & LK500A (1/06-12/06) (04-001) - PUMP-OIL (FITTING PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
836 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VG15010Z5501 | [1] | ENGINE OIL PUMP | KOBPUMP ASSY-OIL (INNER PAKTS E1508) |
| 2. | VG15016J2000 | [1] | GASKET | KOBGASKET-OIL PUMP |
| 3. | VG0812088010 | [5] | SCREW | KOBBOLT,W/WASHER, Start Year: 01-MAY-86 |
| 4. | VG0891513810 | [5] | WASHER SPRING WASHER-SPRING, Years: -01-APR-86 | WASHER SPRING WASHER-SPRING, Years: -01-APR-86 |
| 5. | VG15050Z5505 | [1] | SCREEN-OIL,FOR A1 ONLY | |
| 5. | VG15050Z5501 | [1] | SCREW | KOBSCREEN-OIL,FOR A2 ONLY |
| 6. | VG15066J2000 | [1] | GASKET | KOBGASKET-FLANGE Superseded by part number: VG1505350T00 |
| 7. | VG0811082062 | [2] | BOLT | KOBBOLT,W/WASHER |
| 8. | VG0811081662 | [2] | BOLT BOLT,W/WASHER | BOLT BOLT,W/WASHER |
