| 1. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Net Duckbill
|
| 3. |
47463423
|
[1] |
PLATE
|
NH
|
| 4. |
47448390
|
[1] |
SUPPORT
|
NH
|
| 5. |
47756769
|
[1] |
SHIELD
|
NH
Rubber
|
| 6. |
84597560
|
[1] |
SHIELD
|
NH
|
| 7. |
87661358
|
[1] |
ANGLE
|
NH
|
| 8. |
87028495
|
[1] |
SPRING
|
PA
Superseded by part number: 87652453
|
| 9. |
29684
|
[1] |
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
|
NH
|
| 10. |
87521161
|
[1] |
BUSHING,20.2mm ID x 44.5mm OD x 10.5mm Thk
|
NH
|
| 11. |
47613735
|
[1] |
BUSHING
|
NH
|
| 12. |
9670066
|
[1] |
FLANGE BOLT,Hex, M12 x 30mm, Cl 8.8
|
NH
|
| 13. |
9804261
|
[3] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 14. |
9804278
|
[3] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 15. |
322
|
[7] |
WASHER,8.73mm ID x 42.07mm OD x 3.43mm Thk
|
NH
|
| 16. |
47942976
|
[1] |
SPRING,Extension, 63.5mm OD x 214mm L
|
NH
|
| 17. |
86516632
|
[1] |
SPRING,Extension, 1-3/8" OD x 6-9/16" L
|
ZED
|
| 18. |
631201
|
[2] |
EYEBOLT
|
NH
|
| 19. |
285072
|
[2] |
WASHER,10.3mm ID x 22.2mm OD x 2.7mm Thk
|
NH
|
| 20. |
9628503
|
[4] |
NUT,3/8"-16, G5
|
NH
|
| 21. |
9804277
|
[15] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 22. |
84062222
|
[1] |
BOLT,Hex, M10 x 45mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 8900127036
|
| 23. |
87530646
|
[1] |
HEX SOC SCREW,FLAT, M12 x 1.75 x 25mm, Cl 10.9
|
FAR
|
| 24. |
47421209
|
[1] |
SPACER,13.5mm ID x 50.8mm OD x 7mm L
|
PLO
|
| 25. |
86507486
|
[15] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 26. |
86633356
|
[2] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 27. |
86624468
|
[1] |
SPACER,1.65" L x 5/16” Thk
|
NH
|
| 28. |
86594422
|
[1] |
SENSOR
|
NH
|
| 29. |
87310126
|
[2] |
SCREW,Phillips Drive, Pan HD, #10 - 24 x 3/4", SST
|
BUR
|
| 30. |
86900323
|
[2] |
NUT,#10 - 24
|
PA
|
