现代零件查询15/18/20BT-7 STEERING AXLEEPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
570 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
81FY-57011
|
[1] |
STEERING AXLE ASSY
|
|
| 1-1. |
81FY-57110
|
[1] |
STEERING AXLE WA
|
|
| 1-2. |
81FY-57120
|
[1] |
BRACKET-S/AXLE
|
|
| 1-3. |
B51410060
|
[1] |
BEARING-TAPER ROLLER
|
|
| 1-4. |
B51410070
|
[1] |
BEARING-TAPER ROLLER
|
|
| 1-5. |
B51410080
|
[1] |
SEAL-OIL
|
|
| 1-6. |
81FA-52400
|
[2] |
SEAL-OIL,T6285
|
|
| 1-7. |
81FA-53070
|
[2] |
BEARING-TAPER ROLLER
|
|
| 1-8. |
81FG-50700
|
[2] |
BEARING-T/ROLLER
|
|
| 1-9. |
81FY-57130
|
[2] |
HUB
|
|
| 1-10. |
81FA-52500
|
[2] |
WASHER
|
|
| 1-11. |
S461-630562
|
[2] |
PIN-SPLIT
|
|
| 1-12. |
3677010800-02
|
[12] |
BOLT-HUB
|
|
| 1-13. |
Q100881001
|
[2] |
CAP-HUB
|
|
| 1-14. |
B51410143
|
[1] |
STEERING GEAR ASS'Y
|
|
| 1-14-2. |
81FY-50020
|
[2] |
PIN-STOPPER
|
|
| 1-14-3. |
S411-160002
|
[2] |
WASHER-SPRING
|
|
| 1-14-4. |
S205-160002
|
[2] |
NUT-HEX
|
|
| 1-15. |
81FY-57140
|
[1] |
BEARING
|
|
| 2. |
S017-140506
|
[6] |
BOLT-HEX
|
|
| 3. |
S411-140006
|
[6] |
WASHER-SPRING
|
|
| 4. |
S471-600634
|
[2] |
PIN-SPRING
|
|
| 5. |
81FY-57020
|
[1] |
PINION-STEERING
|
|
| 6. |
F23600280
|
[1] |
SPECIAL WASHER
|
|
| 7. |
S035-082526
|
[1] |
BOLT-W/WASHER
|
|
| 8. |
B51410190
|
[1] |
LEVER
|
|
| 9. |
S015-050256
|
[1] |
BOLT-HEX
|
|
| 10. |
S411-050006
|
[1] |
WASHER-SPRING
|
|
| 11. |
S403-05200B
|
[1] |
WASHER-PLAIN
|
|
| 12. |
S205-051006
|
[1] |
NUT-HEX
|
|
| 13. |
B51410180
|
[1] |
BRACKET
|
|
| 13. |
81FY-59050
|
[1] |
BRACKET
|
|
| 13. |
B51410180
|
[1] |
BRACKET
|
|
| 13. |
81FY-59050
|
[1] |
BRACKET
|
|
| 13. |
B51410180
|
[1] |
BRACKET
|
|
| 13. |
81FY-59050
|
[1] |
BRACKET
|
|
| 14. |
S109-120556
|
[2] |
BOLT-SOCKET
|
|
| 15. |
S411-120006
|
[2] |
WASHER-SPRING
|
|
