Pos.	Part No	Qty	Parts name	Comments
2.	71FV-20070	[1]	STEERING COLUMN	15BT
2.	31FH-10100	[1]	COLUMN ASSY (442MM)	15BT
2.	71FV-20070	[1]	STEERING COLUMN	18BT
2.	31FH-10100	[1]	COLUMN ASSY (442MM)	18BT
2.	71FV-20070	[1]	STEERING COLUMN	20BT
2.	31FH-10100	[1]	COLUMN ASSY (442MM)	20BT
3.	71HA-20300	[1]	STEERING WHEEL ASSY	15BT
3.	71HA-20300G	[1]	STEERING WHEEL	15BT
3.	71HA-20300	[1]	STEERING WHEEL ASSY	18BT
3.	71HA-20300G	[1]	STEERING WHEEL	18BT
3.	71HA-20300	[1]	STEERING WHEEL ASSY	20BT
3.	71HA-20300G	[1]	STEERING WHEEL	20BT
3-1.	71HA-20310	[1]	HORN CAP	15BT
3-1.	71HA-20300G-06	[1]	CAP-HORN	15BT
3-1.	71HA-20310	[1]	HORN CAP	18BT
3-1.	71HA-20300G-06	[1]	CAP-HORN	18BT
3-1.	71HA-20310	[1]	HORN CAP	20BT
3-1.	71HA-20300G-06	[1]	CAP-HORN	20BT
3-2.	0034-0578	[1]	STEERING KNOB KIT	15BT
3-2.	71HA-20300G-02	[1]	KNOB-UPPER	15BT
3-2.	0034-0578	[1]	STEERING KNOB KIT	18BT
3-2.	71HA-20300G-02	[1]	KNOB-UPPER	18BT
3-2.	0034-0578	[1]	STEERING KNOB KIT	20BT
3-2.	71HA-20300G-02	[1]	KNOB-UPPER	20BT
3-3.	71HA-20300G-03	[1]	KNOB-LOWER	15BT
3-3.	71HA-20300G-03	[1]	KNOB-LOWER	18BT
3-3.	71HA-20300G-03	[1]	KNOB-LOWER	20BT
5.	S037-102526	[4]	BOLT-W/WASHER
14.	71FH-41101	[1]	BRACKET-STEERING UNIT
15.	FAD0600070	[1]	NUT-ADJUST
16.	FAD0600080	[2]	WASHER
17.	FAD0600110	[1]	BOLT-ADJUST
18.	71FH-20021	[1]	BRACKET-COLUMN
19.	S035-082026	[2]	BOLT-W/WASHER
20.	S017-122256	[1]	BOLT-HEX
21.	S275-120006	[1]	NUT-SELF LOCKING
22.	S403-122006	[2]	WASHER-PLAIN
23.	S411-120006	[1]	WASHER-SPRING
24.	71FH-20040	[1]	LEVER-ADJUST
25.	71FH-20030	[1]	BOLT-ADJUST
.	71HA-20300SBQ	[1]	KNOB KIT (A/S)	USE A/S
