纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (09-06) - COUNTERWEIGHT, FRONT - HOOK, TOWING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
860 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87617134 | [1] | COUNTERWEIGHT | BURCOUNTERWEIGHT, Front Lower Superseded by part number: 87491427 |
| 2. | 811-12070 | [2] | CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 70mm, Cl 8.8 | CAS Superseded by part number: 338263 |
| 3. | 896-11012 | [2] | WASHER,13.5mm ID x 24mm OD x 3mm Thk | CAS Superseded by part number: 86625255 |
| 4. | 832-10412 | [2] | NUT,M12 x 1.75, Cl 8 | CAS Superseded by part number: 87780366, 412126 |
| 5. | 86577946 | [2] | BOLT,M16 x 2.0 x 90.8mm, Cl 0.9 | FAR |
| 6. | 896-11016 | [2] | WASHER,17.5mm ID x 30mm OD x 4mm Thk | IH Superseded by part number: 86625266 |
| 7. | 405737A2 | [2] | SQUARE NUT | BUR |
| 8. | 87618606 | [8] | SHIM | BURSHIM, Side Wrapper |
| 9. | 87733790 | [1] | PLATE | BURPLATE, Lower Radiator Seal Superseded by part number: 84376545 |
| 10. | 87731498 | [1] | SEAL | BURSEAL, Radiator Bulb |
| 11. | 844-12050 | [3] | BOLT,Hex, M12 x 50mm, Cl 8.8 | BRR Superseded by part number: 9671487 |
| 12. | 87447306 | [3] | SQUARE NUT | CASCage |
| 13. | 450473A1 | [1] | HOOK | BURPull, Front |
| 14. | 827-20120 | [4] | BOLT,Hex, M20 x 2.5 x 120mm, Cl 10.9 | CAS Superseded by part number: 251785 |
| 15. | 896-11020 | [4] | WASHER,22mm ID x 37mm OD x 4mm Thk | CAS Superseded by part number: 86625260 |
