现代零件查询15/18/20BT-7 BRAKE SYSTEMEPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
1007 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
81FY-47012
|
[1] |
BRAKE PEDAL ASSY
|
|
| 1-1. |
81FY-47111
|
[1] |
BRAKE PEDAL WA
|
|
| 1-2. |
C25003011
|
[1] |
PEDAL PAD
|
|
| 1-3. |
S403-201006
|
[1] |
WASHER-PLAIN
|
|
| 1-4. |
S601-020004
|
[1] |
RETAINING RING
|
|
| 1-5. |
81FY-47122
|
[1] |
BRACKET WA
|
|
| 1-6. |
@
|
[1] |
MASTER CYLINDER ASSY
|
|
| 1-7. |
S017-100256
|
[2] |
BOLT-HEX
|
|
| 1-8. |
S411-100006
|
[2] |
WASHER-SPRING
|
|
| 1-9. |
B71350030
|
[1] |
LEVER-MASTER CYL
|
|
| 1-10. |
S491-080252
|
[1] |
PIN-CLEVIS
|
|
| 1-11. |
S403-08100B
|
[1] |
WASHER-PLAIN
|
|
| 1-12. |
S461-200152
|
[1] |
PIN-SPLIT
|
|
| 1-13. |
S015-080406
|
[1] |
BOLT-HEX
|
|
| 1-14. |
S205-081006
|
[1] |
NUT-HEX
|
|
| 1-15. |
FAC0600390-01
|
[1] |
SPRING
|
|
| 1-16. |
F12830090
|
[2] |
SWITCH-BRAKE
|
|
| 1-17. |
B71350040
|
[1] |
BLOCK
|
|
| 1-18. |
S731-020010
|
[2] |
BUSHING-DU
|
|
| 2. |
S037-102526
|
[4] |
BOLT-W/WASHER
|
|
| 3. |
81FQ-40220
|
[1] |
RESERVOIR TANK ASSY
|
|
| 4. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
| 5. |
81FH-40040
|
[1] |
HOSE-BRAKE
|
|
| 6. |
S520-017000
|
[2] |
CLAMP-HOSE
|
|
| 27. |
S543-160002
|
[1] |
CLAMP-TUBE
|
|
| 28. |
S035-081526
|
[1] |
BOLT-W/WASHER
|
|
