现代零件查询15/18/20BT-7 TIREEPC Hyundai _现代Hyundai_工程机械

Pos.	Part No	Qty	Parts name	Comments
.	@	[2]	FRONT TIRE GROUP
1.	B52420050	[2]	TIRE & RIM ASSY	SOLID,15BT
1.	B52420050	[2]	TIRE & RIM ASSY	SOLID,18BT
1-1.	B52420060	[1]	TIRE-SOLID
1-2.	B52420041	[1]	RIM
1.	81FY-20100	[2]	TIRE & RIM ASSY	SOLID,15BT
1.	81FY-20100	[2]	TIRE & RIM ASSY	SOLID,18BT
1-1.	81FH-20420	[1]	TIRE-SOLID
1-2.	B52420041	[1]	RIM
1.	B52440100	[2]	TIRE & RIM ASSY	NON,15BT
1.	B52440100	[2]	TIRE & RIM ASSY	NON,18BT
1-1.	B52440110	[1]	NON-MARKING TIRE
1-2.	B52420041	[1]	RIM
1.	81FY-20800	[2]	TIRE & RIM ASSY	NON,15BT
1.	81FY-20800	[2]	TIRE & RIM ASSY	NON,18BT
1-1.	81FH-20620	[1]	NON-MARKING TIRE
1-2.	B52420041	[1]	RIM
3.	81FY-20310	[2]	TIRE & RIM ASSY(PL)	CS, 15/18BT
3-1.	81FY-20330	[1]	TIRE-CUSHION(PL)
3-2.	81FY-20320	[1]	RIM-FRONT
3.	81FY-20610	[2]	TIRE & RIM ASSY(PL&NM)	CS,NON,15/18BT
3-1.	81FY-20630	[1]	TIRE-CUSHION(PL&NM)
3-2.	81FY-20320	[1]	RIM-FRONT
1.	81FY-22110	[2]	TIRE & RIM ASSY	SOLID,20BT
1-1.	81FY-22120	[1]	TIRE-SOLID
1-1.	81FY-22121	[1]	TIRE-SOLID
1-2.	81FY-22130	[1]	RIM-FRONT
1.	81FY-22810	[2]	FRONT TIRE & RIM ASSY	NON, 20BT
1-1.	81FY-22820	[1]	TIRE-NON MARKING
1-1.	81FY-22821	[1]	TIRE-NON MARKING
1-2.	81FY-22130	[1]	RIM-FRONT
1.	81FY-23310	[2]	TIRE & RIM ASSY-CUSHION	CS, 20BT
1-1.	81FY-23330	[1]	TIRE-CUSHION
1-2.	81FY-23320	[1]	RIM-FRONT,CASTING
3.	81FY-23610	[2]	TIRE & RIM ASSY-CUSHION	CS,NON,20BT
3-1.	81FY-23630	[1]	TIRE-CUSHION
3-2.	81FY-23320	[1]	RIM-FRONT,CASTING
2.	81FY-20240-DA	[10]	NUT-WHEEL
.	@	[1]	REAR TIRE GROUP
6.	81FY-24110	[2]	TIRE & RIM ASSY	15BT,OLID
6.	81FY-24111	[2]	TIRE & RIM ASSY	15BT,OLID
6.	81FY-24110	[2]	TIRE & RIM ASSY	18BT,OLID
6.	81FY-24111	[2]	TIRE & RIM ASSY	18BT,OLID
6.	81FY-24110	[2]	TIRE & RIM ASSY	20BT,OLID
6.	81FY-24111	[2]	TIRE & RIM ASSY	20BT,OLID
6-1.	81FY-24120	[1]	REAR-SOLID TIRE	15BT
6-1.	81FY-24121	[1]	REAR-SOLID TIRE	15BT
6-1.	81FY-24120	[1]	REAR-SOLID TIRE	18BT
6-1.	81FY-24121	[1]	REAR-SOLID TIRE	18BT
6-1.	81FY-24120	[1]	REAR-SOLID TIRE	20BT
6-1.	81FY-24121	[1]	REAR-SOLID TIRE	20BT
6-2.	3661008000B-03	[1]	DISC WHEEL ASSY	15BT
6-2.	3661008000B-03	[1]	DISC WHEEL ASSY	18BT
6-2.	3661008000B-03	[1]	DISC WHEEL ASSY	20BT
6-3.	S018-100256	[6]	BOLT-HEX	15BT
6-3.	S018-100256	[6]	BOLT-HEX	18BT
6-3.	S018-100256	[6]	BOLT-HEX	20BT
6-4.	S411-100006	[6]	WASHER-SPRING	15BT
6-4.	S411-100006	[6]	WASHER-SPRING	18BT
6-4.	S411-100006	[6]	WASHER-SPRING	20BT
6-5.	S206-101006	[6]	NUT-HEX	15BT
6-5.	S206-101006	[6]	NUT-HEX	18BT
6-6.	81HH-20210	[1]	WHEEL RIM	15BT
6-6.	81HH-20210	[1]	WHEEL RIM	18BT
6-6.	81HH-20210	[1]	WHEEL RIM	20BT
7.	3678004400-02	[12]	NUT-HUB
6.	81FY-24810	[2]	TIRE & RIM ASSY	15BT,ON MARKING
6.	81FY-24811	[2]	TIRE & RIM ASSY	15BT,ON MARKING
6.	81FY-24810	[2]	TIRE & RIM ASSY	18BT,ON MARKING
6.	81FY-24811	[2]	TIRE & RIM ASSY	18BT,NON MARKING
6.	81FY-24810	[2]	TIRE & RIM ASSY	20BT,NON MARKING
6.	81FY-24811	[2]	TIRE & RIM ASSY	20BT,NON MARKING
6-1.	81FY-24820	[1]	REAR-NON MARKING TIRE	15BT
6-1.	81FY-24821	[1]	REAR-NON MARKING TIRE	15BT
6-1.	81FY-24820	[1]	REAR-NON MARKING TIRE	18BT
6-1.	81FY-24821	[1]	REAR-NON MARKING TIRE	18BT
6-1.	81FY-24820	[1]	REAR-NON MARKING TIRE	20BT
6-1.	81FY-24821	[1]	REAR-NON MARKING TIRE	20BT
6-2.	3661008000B-03	[1]	DISC WHEEL ASSY
6-2.	3661008000B-03	[1]	DISC WHEEL ASSY
6-2.	3661008000B-03	[1]	DISC WHEEL ASSY
6-3.	S018-100256	[6]	BOLT-HEX	15BT
6-3.	S018-100256	[6]	BOLT-HEX	18BT
6-3.	S018-100256	[6]	BOLT-HEX	20BT
6-4.	S411-100006	[6]	WASHER-SPRING	15BT
6-4.	S411-100006	[6]	WASHER-SPRING	18BT
6-4.	S411-100006	[6]	WASHER-SPRING	20BT
6-5.	S206-101006	[6]	NUT-HEX	15BT
6-5.	S206-101006	[6]	NUT-HEX	18BT
6-5.	S206-101006	[6]	NUT-HEX	20BT
6-6.	81HH-20210	[6]	WHEEL RIM	15BT
6-6.	81HH-20210	[6]	WHEEL RIM	18BT
6-6.	81HH-20210	[6]	WHEEL RIM	20BT
7.	3678004400-02	[12]	NUT-HUB
8.	81FY-25310	[2]	TIRE & RIM ASSY-CUSHION	CUSHION
8-1.	81FY-25330	[1]	TIRE-CUSHION
8-2.	81FY-25010	[1]	RIM-REAR,CASTING
7.	3678004400-02	[12]	NUT-HUB
8.	81FY-25610	[2]	TIRE & RIM ASSY-CUSHION	SM,NON MARK
8-1.	81FY-25630	[1]	TIRE-CUSHION,N/MARK
8-2.	81FY-25010	[1]	RIM-REAR,CASTING
7.	3678004400-02	[12]	NUT-HUB
10.	81FY-24210	[2]	TIRE & RIM ASSY	18BT
10-1.	81FY-24220	[1]	TIRE-SOLID	18BT
10-2.	81FY-24230	[1]	RIM	18BT
7.	3678004400-02	[12]	NUT-HUB	18BT
10.	81FY-24210	[1]	TIRE & RIM ASSY	20BT
10-1.	81FY-24220	[1]	TIRE-SOLID	20BT
10-2.	81FY-24230	[1]	RIM	20BT
7.	3678004400-02	[12]	NUT-HUB	20BT
10.	81FY-24910	[1]	TIRE & RIM ASSY	18BT
10-1.	81FY-24920	[1]	TIRE-NON MARKING	18BT
10-2.	81FY-24230	[1]	RIM	18BT
7.	3678004400-02	[1]	NUT-HUB	18BT
10.	81FY-24910	[1]	TIRE & RIM ASSY	20BT
10-1.	81FY-24920	[1]	TIRE-NON MARKING	20BT
10-2.	81FY-24230	[1]	RIM	20BT
7.	3678004400-02	[1]	NUT-HUB	20BT
