凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (68.170.AM[04]) - VAR - 726666, 726964 - NET WRAP NET BRAKE AND SHIELD, YFN188619 AND AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
255 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47917928
|
[1] |
SHIELD
|
NH
Net/Twine
|
| 2. |
47894638
|
[1] |
SUPPORT
|
NH
|
| 3. |
47756692
|
[1] |
SHAFT
|
NH
Net Counter Roller
|
| 4. |
87026611
|
[1] |
SHEET METAL
|
PA
Net Stuffer
|
| 5. |
84569292
|
[1] |
ROLLER
|
PLO
Net Counter, Incl 18 - 20
|
| 6. |
87521161
|
[2] |
BUSHING,20.2mm ID x 44.5mm OD x 10.5mm Thk
|
NH
|
| 7. |
86507486
|
[6] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 8. |
80664
|
[6] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 9. |
9804277
|
[10] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 10. |
86633356
|
[2] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 11. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
9671714
|
[8] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 13. |
381014
|
[1] |
SCREW,Flng, M8 x 16mm
|
NH
|
| 14. |
80702
|
[1] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 15. |
86050286
|
[1] |
FLANGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 16. |
87395
|
[2] |
COTTER PIN,1/8" OD x 1-1/4" OAL
|
NH
|
| 17. |
140021
|
[3] |
WASHER,22mm ID x 37mm OD x 3mm Thk
|
NH
|
| 18. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Net Counter Roller, Incl with 5
|
