| 1. |
47565530
|
[1] |
PLATE
|
NH
Incl 28
|
| 2. |
9804276
|
[16] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 3. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 4. |
47363963
|
[1] |
KNIFE HOLDER
|
NH
, Serial Range: -YFN188618 Superseded by part number: 47782559
|
| 4. |
47782559
|
[1] |
KNIFE HOLDER
|
NH
, Start Serial: YFN188619
|
| 5. |
86593724
|
[2] |
KNIFE,445.8mm L x 38.1mm W x 3.4mm Thk
|
PA
6 Slots Superseded by part number: 87013989
|
| 6. |
9806864
|
[2] |
KNIFE,382mm L x 38.1mm W x 3.4mm Thk
|
NH
3 Slots
|
| 7. |
9804257
|
[2] |
FLANGE BOLT,Hex, M6 x 1.0 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 8. |
47840554
|
[1] |
PLATE
|
NH
|
| 9. |
87521161
|
[2] |
BUSHING,20.2mm ID x 44.5mm OD x 10.5mm Thk
|
NH
|
| 10. |
698748
|
[1] |
BUSHING,10.3mm ID x 15.88mm OD x 9.53mm L
|
NH
Superseded by part number: 626698
|
| 11. |
87010656
|
[1] |
CLAMP,17.5mm, Coat, 10.3mm Bolt Hole, P Type
|
GI
|
| 12. |
9804261
|
[1] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 13. |
47531156
|
[1] |
SUPPORT
|
PLO
|
| 14. |
87310126
|
[2] |
SCREW,Phillips Drive, Pan HD, #10 - 24 x 3/4", SST
|
BUR
|
| 15. |
86512439
|
[14] |
CARRIAGE BOLT,M6 x 16mm, Cl 8.8
|
NH
|
| 16. |
9804262
|
[1] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 17. |
86900323
|
[2] |
NUT,#10 - 24
|
PA
|
| 18. |
9804255
|
[3] |
BOLT,Hex, M6 x 1 x 16mm, Full Thd, Cl 8.8
|
NH
|
| 19. |
86505868
|
[1] |
SERRATED NUT,Hex, M8 x 1.25, Cl 8
|
ZED
|
| 20. |
86594422
|
[1] |
SENSOR
|
NH
|
| 21. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 22. |
86624468
|
[1] |
SPACER,1.65" L x 5/16” Thk
|
NH
Net Knife
|
| 23. |
87395
|
[1] |
COTTER PIN,1/8" OD x 1-1/4" OAL
|
NH
|
| 24. |
47836146
|
[1] |
PIVOT
|
NH
|
| 25. |
86642464
|
[1] |
WASHER,11mm ID x 30mm OD x 2.5mm Thk
|
FAR
|
| 26. |
86624166
|
[3] |
WASHER,0.91" ID x 1.5" OD x 0.06" Thk
|
FOR
|
| 27. |
47441445
|
[1] |
WIPER MOTOR,12V
|
NH
|
| 28. |
47377884
|
[1] |
WARNING DECAL
|
NH
Incl in 1
|
