纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (09-10) - DOOR, REAR - TANK, HYDRAULIC OIL New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
820 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87443145 | [1] | DOOR ASSY. | BURRight-Hand, Rear; Hydraulic Tank |
| 2. | 627-10025 | [2] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9, Full Thd | CAS Superseded by part number: 11106231 |
| 3. | 895-11010 | [2] | WASHER,11mm ID x 20mm OD x 2mm Thk | CAS Superseded by part number: 14496621 |
| 4. | 122958A1 | [2] | SQUARE NUT | CASM10 Superseded by part number: 230427A1 |
| 5. | 336371A1 | [2] | PIN | CASNut Retainer |
| 6. | 328534A1 | [1] | BOLT | CASStriker |
| 7. | 896-11012 | [1] | WASHER,13.5mm ID x 24mm OD x 3mm Thk | CAS Superseded by part number: 86625255 |
| 8. | 425-107 | [1] | NUT,7/16"-14, G5 | CAS Superseded by part number: 280717 |
| 9. | 87648263 | [1] | ROD ASSY. | BUR340 mm |
| 10. | 432-48 | [1] | COTTER PIN,1/16" x 1/2" | CAS Superseded by part number: 280236, 72187234 |
| 11. | 895-11008 | [1] | WASHER,M8 x 16 x 1.6 | CAS Superseded by part number: 86624184 |
| 12. | R55003 | [1] | LATCH ASSY. | CAS Superseded by part number: 87437076 |
| 13. | 814-6035 | [2] | BOLT,Hex, M6 x 1 x 35mm, Cl 8.8 | CASUsed with (2) 825-2406 M6 Flange Nut Superseded by part number: 86977789 |
| . . | 825-2406 | [2] | FLANGE NUT,M6 x 1, Flg, Cl 8 | CAS Superseded by part number: 9804276 |
| 14. | 492-11025 | [2] | LOCK WASHER,1/4" | CAS Superseded by part number: 80682, 72187247 |
| 15. | L100659 | [1] | CLIP | CASHarness |
