纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (09-14) - SEAT ASSY, MECHANICAL SUSPENSION - MOUNTING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
118 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87450937 | [1] | SEAT ASSY. | BURMechanical Suspension; Black Vinyl; See Figure 09-15 |
| 1A. | 87450938 | [1] | SEAT ASSY. | BURMechanical Suspension; Gray Cloth; See Figure 09-15 |
| 2. | 844-10025 | [4] | BOLT,Hex, M10 x 25mm, Cl 8.8 | CASReplaces 854-10025 M10 x 25, 10.9 Bolt Used On Some Models Superseded by part number: 9804261 |
| 3. | 87408888 | [1] | SAFETY BELT ,76.20 mm W | BUR |
| 4. | 87408889 | [1] | SAFETY BELT ,50.80 mm W | BUR |
| 5. | 496-21053 | [2] | WASHER,17/32" x 1 1/16" x .134" | CAS Superseded by part number: 86624188 |
| 8. | 76067361 | [2] | ARMREST | LEC |
| 9. | 87608818 | [2] | SUPPORT | BHBSUPPORT |
| 10. | 614-8016 | [8] | BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd | CAS Superseded by part number: 16043224 |
| 11. | 895-11008 | [8] | WASHER,M8 x 16 x 1.6 | CAS Superseded by part number: 86624184 |
| 12. | 76067464 | [2] | SEAL | LECSeal, Armrest Tube |
| 13. | 87446967 | [2] | HANDLE | BURArmrest, Plastic Handle; Replaces 76067236 Metal Handle Used On Some Models |
| 14. | D150393 | [1] | BRACKET | CASInner Support |
