凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (68.180.BO[03]) - TWINE ARM, P.I.N. YGN190999 AND AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
978 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47900203
|
[1] |
MOUNT
|
NH
Twine Arm
|
| 2. |
47930327
|
[1] |
SUPPORT
|
NH
Incl 12
|
| 3. |
84247408
|
[1] |
SPROCKET,RC 35, 72T
|
PLO
|
| 4. |
84592195
|
[1] |
PLATE
|
NH
|
| 5. |
300595
|
[2] |
COTTER PIN,M4 x 40
|
WIN
Superseded by part number: 10733901
|
| 6. |
140109
|
[4] |
WASHER,31mm ID x 40mm OD x 2mm Thk
|
NH
|
| 7. |
9804262
|
[1] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 8. |
9804278
|
[1] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 9. |
47537037
|
[2] |
PLATE
|
PLO
|
| 10. |
87414
|
[2] |
LUBE NIPPLE,1/4" - 28
|
NH
|
| 11. |
291595
|
[1] |
TUBE,19.05 mm OD, 530.35, 88.9 mm Length
|
BEL
RC35
|
| 12. |
420434
|
[1] |
BUSHING,30mm ID x 34mm OD x 20mm L
|
NH
RC35
|
