凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (68.180.BO[04]) - TWINE ARM ELECTRIC Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
875 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Twine Arm Pivot
|
| 2. |
47441445
|
[1] |
WIPER MOTOR,12V
|
NH
Twine Arm
|
| 3. |
84258225
|
[1] |
SPROCKET,RC35, 11T
|
NH
11T, RC35
|
| 4. |
84308004
|
[1] |
HUB
|
NH
|
| 5. |
84279849
|
[1] |
ACTUATING PLATE
|
NH
|
| 6. |
84300445
|
[1] |
MOUNT
|
NH
|
| 7. |
86613601
|
[1] |
WASHER,14.88mm ID x 28.69mm OD x 7.35mm Thk
|
NH
|
| 8. |
86977396
|
[1] |
POTENTIOMETER,3000 Ohm, 16 VDC
|
PA
|
| 9. |
9804262
|
[4] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 10. |
9804278
|
[4] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 11. |
86505868
|
[1] |
SERRATED NUT,Hex, M8 x 1.25, Cl 8
|
ZED
|
| 12. |
9672521
|
[1] |
LOCK WASHER,Ext Tooth, #10
|
WIN
|
| 13. |
412255
|
[2] |
BOLT,Hex, M4 x 20mm, Cl 8.8
|
NH
|
| 14. |
86000439
|
[1] |
SNAP RING,0.288" ID x 0.66" OD x 0.037" Thk, External
|
NH
|
| 15. |
84259286
|
[1] |
CHAIN,35, 83 Links x 3/8" = 31-1/8" L
|
NH
83 Pitches, RC35, Incl 18, 19
|
| 16. |
9804256
|
[5] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 17. |
9804276
|
[2] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 18. |
86516818
|
[1] |
CONNECTING LINK
|
GI
RC35
|
| 19. |
117226
|
[1] |
OFFSET LINK
|
GI
RC35 Superseded by part number: 241-3713
|
