纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (09-35) - CAB - WASHER, WINDSHIELD New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
779 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 425-106 | [2] | NUT,3/8"-16, Cl 5 | CAS Superseded by part number: 9628503 |
| 2. | 492-11038 | [2] | LOCK WASHER,3/8" | CAS Superseded by part number: 72187249, 80680 |
| 3. | 905-8020 | [3] | BOLT,Hex Flg, M8 x 20mm | CAS Superseded by part number: 86511479 |
| 4. | 87337962 | [1] | WINDSHIELD WASH RESERVOIR | RAC |
| 5. | 87427778 | [1] | FITTING | CAS |
| 6. | 87628340 | [1] | HOSE WASHER,4.76 mm ID x 660.00 mm | BURHOSE WASHER, Windshield, Service from 397154A1 Bulk |
| 7. | 87628341 | [1] | HOSE WASHER,4.76 mm ID x 2270.00 mm | BURCab Feed; Service from 397154A1 Bulk |
| 8. | 87628343 | [1] | HOSE WASHER,4.76 mm ID x 2000.00 mm | BURWindshield, Service from 397154A1 Bulk |
| 9. | 87628344 | [1] | HOSE WASHER,4.76 mm ID x 410.00 mm | BURWindshield; Service from 397154A1 Bulk |
| 10. | 87699963 | [1] | WIRE HARNESS | BURHARNESS, Windshield Washer |
| 11. | 284154A1 | [2] | NOZZLE,3/8" - 16 | CAS |
| 12. | 305578A1 | [2] | CLAMP,7.65mm - 8.76mm | CAS |
| 13. | D47783 | [3] | CLAMP | CAS Superseded by part number: 577927 |
| 14. | L11541 | [7] | CABLE TIE,203.2mm L, Nylon | CAS Superseded by part number: 87000312 |
| 15. | 82036769 | [1] | FILLER CAP | BAS |
