神钢零件查询(FD6T04) - NISSAN DIESEL ENGINE - LK500 (1/06-12/06) (02-004) - FLYWHEEL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
529 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONFLYWHEEL |
| 1-2. | VG12310Z5516 | [1] | FLYWHEEL ASSY,FOR 81 ONLY | |
| 1-2. | VG12310Z5518 | [1] | FLYWHEEL ASSY,FOR 72 ONLY | |
| 1-2. | VG12310Z5519 | [1] | FLYWHEEL ASSY,FOR 46,47,56,57 ONLY | |
| 1-2. | VG12310Z5512 | [1] | ENGINE FLYWHEEL | KOBFLYWHEEL ASSY,FOR 41,46,51,71,76 ONLY |
| 2. | VG12312Z5001 | [1] | RING GEAR | KOBGEAR-RING Superseded by part number: VG12312Z5500 |
| 3. | VG0152206124 | [2] | PIN-STRAIGHT,FOR 81 ONLY | |
| 3. | VG0152210224 | [2] | PIN PIN-STRAIGHT,FOR 41,51,71,76 ONLY | PIN PIN-STRAIGHT,FOR 41,51,71,76 ONLY |
| 4. | VG21023Z5000 | [1] | BEARING-BALL, FOR 81 ONLY | |
| 5. | VG12314Z5000 | [3] | LOCK WASHER | KOBWASHER-LOCK |
| 6. | VG0813444510 | [6] | BOLT BOLT | BOLT BOLT |
| 7. | VG32457Z5502 | [1] | ADAPTER-FLYWHEEL, FOR 72 ONLY | |
| 8. | VG0812103028 | [8] | BOLT | KOBB0LT, W/WA5HER, FOR 72 ONLY |
