神钢零件查询(FD6T04) - NISSAN DIESEL ENGINE - LK500 (1/06-12/06) (03-005) - TURBOCHARGER-EXHAUST(FITTING PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
395 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONTURBO CHARGER-EXHAUST (FITTING PARTS) |
| 1. | VG14201Z5500 | [1] | TURBOCHARGER | KOBTURBO ASSY-EXHAUST (INNER PARTS 03-006) |
| 2. | VG1433595001 | [1] | GASKET | KOBGASKET |
| 3. | VG0115103164 | [4] | STUD | KOBSTUD |
| 4. | VG0121100014 | [8] | NUT | KOBNUT Superseded by part number: 76602149 |
| 5. | VG14234Z5501 | [1] | ADAPTER-OIFFUSER ADAPTER-DIFFUSER | ADAPTER-OIFFUSER ADAPTER-DIFFUSER |
| 6. | VG0115103144 | [1] | KNIFE COVER | KOBSTUD |
| 7. | VG0115103344 | [1] | STUD STUD | STUD STUD |
| 8. | VG0121100014 | [4] | NUT | KOBNUT Superseded by part number: 76602149 |
| 9. | VG0193502054 | [1] | STAY STAY | STAY STAY |
| 10. | VG14233Z5503 | [1] | EXHAUST MANIFOLD | KOBDIFFUSER-EXH, FOR 51,56,57,71,76,81 ONLY |
| 10. | VG14233Z5505 | [1] | DIFFUSER-EXH, FOR 72 ONLY | |
| 11. | VG0115103344 | [4] | STUD STUD | STUD STUD |
| 12. | VG1403995000 | [8] | NUT | KOBNUT Superseded by part number: 76602149 |
| 13. | VG1405495000 | [1] | RING GEAR | KOBRING DIFFUSER |
| 14. | VG9102890001 | [1] | PLUG | KOBPLUG-TAPER, FOR 51,56,57,71,76,81 ONLY |
| 15. | VG15116Z5508 | [1] | PIPE | KOBPIPE ASSY-OIL |
| 16. | VG9101990004 | [1] | WASHER WASHER-PLAIN | WASHER WASHER-PLAIN |
| 17. | VG0161900324 | [1] | SCREW | KOBBOLT-EYE |
| 18. | VG0135121124 | [2] | GASKET | KOBGASKET |
| 19. | VG0811081662 | [1] | BOLT BOLT, W/WASHER | BOLT BOLT, W/WASHER |
| 20. | VG15114Z5509 | [1] | PIPE PIPE-OIL DRAIN | PIPE PIPE-OIL DRAIN |
| 21. | VG9945096102 | [2] | CLIP CLIP | CLIP CLIP |
| 22. | VG1511796001 | [2] | FLANGE | KOBFLANGE |
| 23. | VG1511896001 | [2] | RUBBER RING | KOBO-RING |
| 24. | VG1511797000 | [2] | FLANGE FLANGE | FLANGE FLANGE |
| 25. | VG1233497000 | [2] | GASKET-FLANGE | |
| 26. | VG0811083525 | [2] | BOLT BOLT,W/WASHER | BOLT BOLT,W/WASHER |
| 27. | VG99450Z5516 | [1] | STAY STAY | STAY STAY |
| 28. | VG0811081662 | [2] | BOLT BOLT, W/WASHER | BOLT BOLT, W/WASHER |
| 29. | VG0891543810 | [2] | WASHER WASHER-PLAIN | WASHER WASHER-PLAIN |
| 30. | VG9675590000 | [1] | SPACER SPACER | SPACER SPACER |
| 31. | VG0193512504 | [1] | STAY STAY | STAY STAY |
| 32. | VG0801100410 | [1] | BOLT BOLT | BOLT BOLT |
