神钢零件查询(FD6T04) - NISSAN DIESEL ENGINE - LK500 (1/06-12/06) (03-006) - TURBOCHARGER-EXHAUST(INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
619 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONTURBO CHARGER EXHAUST(INNER PARTS) |
| 1-31. | VG14201Z5500 | [1] | TURBOCHARGER | KOBTURBO CHARGER ASSY |
| 1. | VG14208Z9000 | [1] | HOUSING ASSY HOUSING ASSY | HOUSING ASSY HOUSING ASSY |
| 2. | VG1420799001 | [1] | SET OF STD MAIN BRGS | KOBBEARING |
| 3. | VG1423699000 | [4] | RETAINER | KOBRING-RETAINER |
| 4. | VG1420499001 | [1] | TURBINE | KOBWHEEL A5SY-TURBIN |
| 5. | VG1420599004 | [1] | PISTON RING | KOBRING-PISTON |
| 6. | VG1420599003 | [1] | PISTON RING | KOBRING-PISTON |
| 7. | VG1421599001 | [1] | COLLAR CLAMP | KOBCOLLAR-THRUST |
| 8. | VG14226Z9000 | [1] | WHEEL COMPRESSOR WHEEL-COMPRESSOR | WHEEL COMPRESSOR WHEEL-COMPRESSOR |
| 9. | VG1422599001 | [1] | NUT LOCK NUT | NUT LOCK NUT |
| 10. | VG1421499001 | [1] | SET OF STD MAIN BRGS | KOBBEARING-THRUST |
| 11. | VG1422299004 | [1] | PLATE | KOBPLATE-BACK |
| 12. | VG1421799000 | [1] | SEAL RETAINER | KOBRING-SEAL |
| 13. | VG1422399002 | [1] | WHEEL WHEEL-SHROUD | WHEEL WHEEL-SHROUD |
| 14. | VG1421999000 | [2] | PLATE | KOBPLATE |
| 15. | VG1421899000 | [4] | BOLT BOLT | BOLT BOLT |
| 16. | VG1422699002 | [1] | HOUSING HOUSING-COMPRESSOR | HOUSING HOUSING-COMPRESSOR |
| 17. | VG1421999006 | [3] | PLATE PLATE | PLATE PLATE |
| 18. | VG1422199004 | [3] | CLAMP CLAMP | CLAMP CLAMP |
| 19. | VG1422099004 | [6] | SCREW | KOBBOLT |
| 20. | VG1421999002 | [3] | PLATE | KOBPLATE |
| 21. | VG1422199005 | [2] | CLAMP | KOBCLAMP |
| 22. | VG1422099003 | [6] | SCREW | KOBBOLT |
| 23. | VG14202Z9003 | [1] | HOUSING HOUSING-TURBIN | HOUSING HOUSING-TURBIN |
| 24. | VG1421099003 | [1] | ADAPTER ADAPTER-INLET | ADAPTER ADAPTER-INLET |
| 25. | VG1421399004 | [1] | ADAPTER ADAPTER-OUTLET | ADAPTER ADAPTER-OUTLET |
| 26. | VG1420999001 | [1] | GASKET | KOBGASKET |
| 27. | VG1421299000 | [1] | GASKET | KOBGASKET |
| 28. | VG14220Z9000 | [2] | BOLT BOLT | BOLT BOLT |
| 29. | VG14220Z9001 | [2] | BOLT BOLT | BOLT BOLT |
| 30. | VG1422799000 | [2] | WASHER WASHER-SPRING | WASHER WASHER-SPRING |
| 31. | VG14227Z9000 | [2] | WASHER WASHER-SPRING | WASHER WASHER-SPRING |
| . . | VG14201Z9000 | [1] | KIT | KOB(NOTE) ROTATING KIT (INC. KEY N0.17-22, 26,27,30,31) |
