神钢零件查询(FD6T04) - NISSAN DIESEL ENGINE - LK500 (1/06-12/06) (05-004) - PUMP INJECTION (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
862 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-56. | VG16703Z5500 | [1] | PUMP ASSY-INJECTION, FOR 51,56,57 ONLY | |
| 1-56. | VG16703Z5504 | [1] | PUMP ASSY-INJECTION, FOR 41,46,47 ONLY | |
| 1-3. | VG1670299010 | [1] | HOUSING ASSY, FOR 51,56,57 ONLY | |
| 1-3. | VG16702Z9000 | [1] | HOUSING ASSY, FOR 41,46,47 ONLY | |
| 2. | VG1672937500 | [3] | STUD, FEED PUMP | |
| 3. | VG1675237500 | [1] | ADAPTER | |
| 4. | VG1672095001 | [1] | COVER COVER | COVER COVER |
| 5. | VG1672337503 | [2] | SCREW | KOBSCREW Superseded by part number: 76602279 |
| 6. | VG1671637500 | [2] | GASKET | KOBGASKET Superseded by part number: 76602277 |
| 7. | VG1671437501 | [6] | PLUG | |
| 8. | VG1682590004 | [3] | WASHER-SPRING | |
| 9. | VG0891120610 | [3] | NUT | KOBNUT |
| 10. | VG1927899014 | [1] | O-RING | KOBO RING Superseded by part number: 76602421 |
| 11. | VG16760Z9000 | [6] | PLUNGER | KOBPLUNGER ASSY, FOR 51,56,57 ONLY |
| 11. | VG16760Z9004 | [6] | PLUNGER ASSY, FOR 41,46,47 ONLY | |
| 12. | VG1677399002 | [6] | VALVE | KOBVALVE-DELIVERY |
| 13. | VG1677695000 | [6] | SPRING | |
| 14. | VG16777Z9000 | [6] | GA5KET | |
| 15. | VG1677895000 | [6] | HOLDER HOLDER-DELIVERY | HOLDER HOLDER-DELIVERY |
| 16. | VG1676199002 | [3] | PLATE, FOR 51,56,57 ONLY | |
| 16. | VG16761Z9000 | [3] | PLATE, FOR 41,46,47 ONLY | |
| 17. | VG1927995000 | [6] | O-RING | KOBO RING Superseded by part number: 76593700 |
| 18-24. | VG1674595000 | [6] | TAPPET ASSY | |
| 19. | VG1675137500 | [6] | NUT | |
| 20. | VG1675037500 | [6] | BOLT-TAPPER | |
| 21. | VG1674837500 | [6] | PIN | |
| 22. | VG1674199004 | [6] | ROLLER | |
| 23. | VG1674399003 | [6] | BUSH | |
| 24. | VG1675937500 | [6] | GUIDE | |
| 25. | VG1677037500 | [6] | SPRING-PLUNGER | |
| 26. | VG1676937500 | [6] | SEAT-SPRING, UPPER | |
| 27. | VG1677237500 | [6] | SEAT-SPRING, LOWER | |
| 28. | VG1672795000 | [1] | CONTROL RACK | |
| 29. | VG1672695000 | [1] | SCREW | |
| 30. | VG1676737500 | [6] | PINION | |
| 31. | VG1676637500 | [6] | SLEEVE-CONTROL | |
| 32. | VG1676837500 | [6] | SCREW | |
| 33. | VG16738Z9001 | [1] | CAMSHAFT, FOR 51,56,57 ONLY | |
| 33. | VG16738Z9002 | [1] | CAMSHAFT, FOR 41,46,47 ONLY | |
| 34. | VG1673999001 | [2] | BEARING | |
| 34. | VG1673937500 | [2] | BEARING | |
| 35. | VG1674037500 | [2] | RING | |
| 36. | VG1674137500 | [1] | SHIM, T=0.1 | |
| 36. | VG1674137501 | [1] | SHIM, T=0.12 | |
| 36. | VG1674137502 | [1] | SHIM, T=0.14 | |
| 36. | VG1674137503 | [1] | SHIM, T=0.16 | |
| 36. | VG1674137504 | [1] | SHIM, T=0.18 | |
| 36. | VG1674137505 | [1] | SHIM, T=0.5 | |
| 36. | VG1674137506 | [1] | SHIM, T=0.3 | |
| 36. | VG1674137507 | [1] | SHIM, T=0.7 | |
| 36. | VG1674137508 | [1] | SHIM, T=1.0 | |
| 36. | VG1674199019 | [1] | SHIM, T=1.4, FOR 41,46,47 ONLY | |
| 37. | VG1675461501 | [1] | BEARING-CENTER | |
| 38. | VG1679161500 | [2] | SCREW | |
| 39. | VG1679261500 | [2] | GASKET | |
| 40. | VG1674399001 | [1] | SEAL-OIL | |
| 41. | VG1674499003 | [1] | COVER | |
| 42. | VG1675437501 | [4] | BOLT | |
| 43. | VG1674237500 | [1] | KEY-WOODRUFF | |
| 44. | VG1675337500 | [1] | SCREW | KOBBOLT-EYE |
| 45. | VG1666237500 | [2] | GASKET | |
| 46. | VG16773Z9001 | [1] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE VALVE-OVERFLOW |
| 47. | VG1666237500 | [2] | GASKET | |
| 48. | VG1684299002 | [1] | PLUG | |
| 49. | VG1677899002 | [1] | GASKET | |
| 50. | VG16744Z9000 | [1] | BRACKET | |
| 51. | VG16786J2001 | [1] | O-RING | KOBO-RING |
| 52. | VG0891544001 | [4] | WASHER | |
| 53. | VG1682590006 | [4] | WASHER-SPRING | |
| 54. | VG1675137501 | [4] | NUT | |
| 55. | VG1675737500 | [1] | EYE BOLT BOLT-EYE | EYE BOLT BOLT-EYE |
| 56. | VG1677899001 | [2] | GASKET GASKET | GASKET GASKET |
