神钢零件查询(FD6T04) - NISSAN DIESEL ENGINE - LK500 (1/06-12/06) (03-008) - COMPRESSOR-AIR (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
201 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONCOMPRESSOR -AIR (INNER PARTS) |
| 1-42. | VG14501Z5500 | [1] | AIRCOND. COMPRESSOR | KOBCOMPRESSOR ASSY-AIR,FOR 71 ONLY |
| 1. | VG14506Z9002 | [1] | CASE CRANK CASE-CRANK | CASE CRANK CASE-CRANK |
| 2. | VG14509Z9001 | [1] | CRANKSHAFT T CRANKSHAFT | CRANKSHAFT T CRANKSHAFT |
| 3. | VG14511Z9000 | [2] | BALL BEARING | KOBBEARING-BALL |
| 4. | VG14513Z9000 | [1] | HOUSING HOLDER-BEARING | HOUSING HOLDER-BEARING |
| 5. | VG14514Z9000 | [1] | O-RING | KOBO-RING |
| 6-10. | VG14516Z9000 | [1] | CONNECTING ROD | KOBROD ASSY-CONNECTING |
| 7. | VG14519Z9000 | [2] | SET OF STD MAIN BRGS | KOBMETAL-SHELL |
| 8. | VG14521Z9000 | [2] | BOLT BOLT | BOLT BOLT |
| 9. | VG0891120810 | [2] | NUT NUT | NUT NUT |
| 10. | VG14522Z9000 | [2] | LOCK WASHER | KOBWASHER-LOCK |
| 11. | VG1453290000 | [1] | PIN | KOBPIN-PISTON |
| 12. | VG14528Z9000 | [1] | PISTON | KOBPISTON |
| 13. | VG1453490001 | [2] | PISTON RING SET | KOBCLIP |
| 14. | VG14529Z9025 | [1] | PISTON RINGS KIT | KOBRING KIT |
| 15. | VG14514Z9001 | [1] | O-RING | KOBO-RING |
| 16. | VG14535Z9000 | [1] | LINER, ENGINE CYLIND | KOBLINER |
| 17. | VG14510Z9000 | [1] | DRIVEN GEAR | KOBGEAR |
| 18-34. | VG14540Z9001 | [1] | CYLINDER HEAD | KOBHEAD ASSY |
| 18. | VG14548Z9000 | [1] | HEAD CYLINDER HEAD | HEAD CYLINDER HEAD |
| 19-23. | VG14570Z9025 | [1] | SUCTION PIPE | KOBVALVE KIT-SUCTION |
| 19. | VG1457799000 | [1] | HOLDER HOLDER | HOLDER HOLDER |
| 20. | VG1456896000 | [1] | SPRING | KOBSPRING |
| 21. | VG1457099000 | [1] | VALVE | KOBVALVE |
| 22. | VG1457296000 | [1] | PACKING | KOBPACKING |
| 23. | VG1457199000 | [1] | VALVE SEAT | KOBSEAT |
| 24-26. | VG1455299000 | [1] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE VALVE ASSY-UNLOADER Superseded by part number: 1455299000 |
| 25. | VG1455690001 | [1] | SPRING | KOBSPRING Superseded by part number: 1455690001 |
| 26. | VG1453390001 | [1] | CLIP CLIP | CLIP CLIP |
| 27-31. | VG14569Z9025 | [1] | HYDRAULIC VALVE | KOBVALVE KIT-DELIVERY |
| 27. | VG14555Z9001 | [1] | HOLDER HOLDER ASSY | HOLDER HOLDER ASSY |
| 28. | VG1455096000 | [1] | HYDRAULIC VALVE | KOBSPRING |
| 29. | VG1456999000 | [1] | VALVE | KOBVALVE |
| 30. | VG1455399003 | [1] | VALVE SEAT | KOBSEAT |
| 31. | VG14552Z9000 | [1] | O-RING | KOBO-RING |
| 32. | VG1458299005 | [1] | O-RING | KOBO-RING |
| 33. | VG1455996000 | [1] | CONNECTOR CONNECTOR | CONNECTOR CONNECTOR |
| 34. | VG0996161800 | [1] | PACKING | |
| 35. | VG0811102520 | [8] | BOLT | |
| 36. | VG0891513600 | [6] | WASHER WASHER-SPRING | WASHER WASHER-SPRING |
| 37. | VG0891514000 | [8] | WASHER WASHER-SPRING | WASHER WASHER-SPRING |
| 38. | VG1455799000 | [1] | KEY KEY | KEY KEY |
| 39. | VG1451499011 | [1] | O-RING | KOBO-RING |
| 40. | VG0811062020 | [6] | BOLT BOLT | BOLT BOLT |
| 41. | VG1452299000 | [1] | WASHER WASHER-LOCK | WASHER WASHER-LOCK |
| 42. | VG0891132400 | [1] | NUT NUT-LOCK | NUT NUT-LOCK |
