神钢零件查询(FD6T04) - NISSAN DIESEL ENGINE - LK500 (1/06-12/06) (05-006) - TIMER-AUTOMATIC (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
801 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-14. | VG16810Z5500 | [1] | TIMER ASSY-AUTOMATIC, FOR 51,56,57 ONLY | |
| 1-14. | VG16810Z5503 | [1] | TIMER ASSY-AUTOMATIC, FOR 41,46,47 ONLY | |
| 2. | VG16821Z9001 | [1] | SPRING-TIMER, FOR 51,56,57 ONLY | |
| 2. | VG16821Z9004 | [2] | SPRING-TIMER, FOR 41,46,47 ONLY | |
| 3. | VG1682237500 | [2] | SHIM, T=0.1 | |
| 3. | VG1682237501 | [1] | SHIM, T=0.3 | |
| 3. | VG1682237502 | [1] | SHIM, T=0.5 | |
| 3. | VG1682237503 | [1] | SHIM, T=0.2 | |
| 3. | VG1682237504 | [1] | SHIM, T=0.6 | |
| 3. | VG1682237505 | [1] | SHIM, T=1.0 | |
| 4. | VG16823Z9001 | [1] | FLYWEIGHT, FOR 51,56,57 ONLY | |
| 4. | VG16B23Z9005 | [1] | FLYWEIGHT, FOR 41,46,47 ONLY | |
| 6. | VG1682599000 | [1] | WASHER | |
| 7. | VG1682699000 | [1] | SHIM, T=0.12 | |
| 7. | VG1662699001 | [1] | SHIM, T=0.14 | |
| 7. | VG1682699002 | [1] | SHIM, T=0.16 | |
| 7. | VG1682699003 | [1] | SHIM, T=0.18 | |
| 7. | VG1682699004 | [1] | SHIM, T=0.5 | |
| 7. | VG1682699005 | [1] | SHIM, T=0.2 | |
| 7. | VG1682699006 | [1] | SHIM, T=0.3 | |
| 7. | VG1682699007 | [1] | SHIM, T=0.1 | |
| 8. | VG1682799000 | [1] | WASHER | |
| 9. | VG1682837500 | [1] | PLATE-LOCK | |
| 10. | VG1682937500 | [1] | NUT | |
| 11. | VG0891514200 | [1] | WASHER-SPRING | |
| 11. | VG1683037500 | [1] | WASHER-SPRING | |
| 12. | VG16675Z9000 | [1] | NUT | |
| 13. | VG13052Z5001 | [1] | DRIVING GEAR | KOBGEAR-DRIVE |
| 14. | VG19382Z9003 | [6] | BOLT, W/WASHER | |
