神钢零件查询(FD6T04) - NISSAN DIESEL ENGINE - LK500 (1/06-12/06) (04-001) - PUMP-OIL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
123 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-15. | VG15010Z5001 | [1] | SEPERATE PARTS ONLY PUMP ASSY-OIL | SEPERATE PARTS ONLY PUMP ASSY-OIL |
| 1. | VG15053Z9001 | [1] | COVER COVER | COVER COVER |
| 2. | VG15013Z9001 | [1] | PACKING | KOBPACKING |
| 3. | VG15012Z9000 | [1] | BODY BODY ASSY | BODY BODY ASSY |
| 4. | VG15027Z9001 | [1] | SHAFT | KOBSHAFT-DRIVE |
| 5. | VG15023Z9000 | [1] | GEAR | KOBGEAR-DRIVE |
| 6. | VG15031J2000 | [1] | WASHER WASHER-LOCK | WASHER WASHER-LOCK |
| 7. | VG15032Z9000 | [1] | NUT NUT-HEX | NUT NUT-HEX |
| 8. | VG15026J2000 | [1] | GEAR PUMP GEAR-PUMP | GEAR PUMP GEAR-PUMP |
| 9. | VG15029J2000 | [1] | KEY KEY-WOODRUFF | KEY KEY-WOODRUFF |
| 10. | VG15132J2000 | [1] | VALVE PRESSURE RELIE | KOBVALVE-RELIEF |
| 11. | VG15133Z9000 | [1] | SPRING | KOBSPRING-RELIEF |
| 12. | VG15134J2000 | [1] | GASKET | KOBGASKET |
| 13. | VG15135Z9000 | [1] | PLUG PLUG | PLUG PLUG |
| 14. | VG15020J2000 | [3] | BOLT BOLT | BOLT BOLT |
| 15. | VG0891513810 | [3] | WASHER SPRING WASHER-SPRING | WASHER SPRING WASHER-SPRING |
| 16. | VG15016J2000 | [1] | GASKET | KOBGASKET-OIL PUMP |
| 17. | VG0812088510 | [5] | BOLT BOLT | BOLT BOLT |
| 18. | VG0891513810 | [5] | WASHER SPRING WASHER-SPRING | WASHER SPRING WASHER-SPRING |
