纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (09-56) - DECALS - LATIN AMERICAN SPANISH New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
711 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 334034A1 | [2] | WARNING DECAL | CASEntanglement Hazard |
| 2. | 85804338 | [1] | DECAL | IMODiesel Fuel Fill |
| 3. | 389736A1 | [2] | DECAL | CASDanger; Jump Start, Battery |
| 4. | 389741A1 | [1] | DECAL | CASWarning; Radiator Cap |
| 5. | 124271A1 | [1] | DECAL | CASWarning; Do Not Jump |
| 6. | 87352602 | [1] | DECAL | BURWarning; Read the Operator's Manual |
| 7. | 87634110 | [2] | DECAL | BURSafety Lever |
| 8. | 124281A1 | [1] | DECAL | CASDanger; Engine Start Warning |
| 9. | 87420954 | [1] | DECAL | BURDozer Blade Control Pattern |
| 10. | 87451954 | [1] | LARGE PLATE | CASPLATE, LARGE Decal Mounting, Used With Ref 3, 8, 11, 12 |
| 11. | 614-10025 | [2] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8 | CAS Superseded by part number: 11106231 |
| 12. | 892-11010 | [2] | LOCK WASHER,M10 | CAS Superseded by part number: 140028 |
| 13. | 87355182 | [1] | DECAL | BURImportant; Track Tension |
| 14. | 87701340 | [2] | DECAL | SMLow Emissions |
| 20. | 87422190 | [1] | DECAL | BURRipper Control Pattern |
| 22. | NSS | [1] | NOT SERVICED SEPARATELY | CONNorth American Decal |
| 24. | 8603094 | [1] | WARNING DECAL | FARExplosion Hazard, Do Not Use Ether |
