凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (88.100.62[06]) - DIA KIT, STRAW BULGE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
554 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47822387
|
[1] |
DIA KIT, HARVESTER
|
NH
Twine Straw, Incl 2 - 13
|
| 2. |
47824840
|
[1] |
INSTRUCTION
|
NH
Superseded by part number: 47951741
|
| 3. |
47822347
|
[2] |
MOUNT
|
NH
|
| 4. |
853070
|
[3] |
SPACER,10.2mm ID x 19mm OD x 13mm Thk
|
ZED
|
| 5. |
47770524
|
[1] |
SHIELD
|
NH
Twine Straw
|
| 6. |
84528401
|
[1] |
BRUSH
|
NH
Twine Straw
|
| 7. |
9804262
|
[4] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 8. |
9804278
|
[4] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 9. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 10. |
9804277
|
[5] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 11. |
9804260
|
[3] |
BOLT,Hex, M8 x 1.25 x 30mm, Full Thd, Cl 8.8
|
NH
|
| 12. |
47768409
|
[1] |
BAR
|
NH
Bulge
|
| 13. |
47822382
|
[2] |
PLATE
|
NH
|
