凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (88.100.62[06]) - DIA KIT, TWINE STRAW Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
289 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47950194
|
[1] |
DIA KIT, HARVESTER
|
NH
Twine Straw, Incl 2 - 9
|
| 2. |
47951741
|
[1] |
INSTRUCTION
|
NH
|
| 3. |
47822347
|
[1] |
MOUNT
|
NH
|
| 4. |
9840672
|
[4] |
BOLT,Hex Serr Flg, M10 x 30mm
|
WIN
|
| 5. |
9804278
|
[4] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 6. |
86507486
|
[2] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 7. |
86505868
|
[2] |
SERRATED NUT,Hex, M8 x 1.25, Cl 8
|
ZED
|
| 8. |
47950193
|
[1] |
BAR
|
NH
|
| 9. |
47822382
|
[2] |
PLATE
|
NH
|
