凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (88.100.68[01]) - DO NOT SELL - DIA KIT, TWINE CONVERSION KIT, DELUXE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
416 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47658966
|
[1] |
DIA KIT, HARVESTER
|
NH
Twine Conversion, Deluxe, Incl 2 - 22
|
| 2. |
84394662
|
[1] |
INSTRUCTION
|
PLO
|
| 3. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Twine Knife Assembly, Incl in 1, Refer to Figure 68.180.BB
|
| 4. |
47488322
|
[1] |
WIRE HARNESS
|
NH
BA Superseded by part number: 47938503
|
| 7. |
84580514
|
[1] |
SUPPORT
|
NH
|
| 8. |
84572188
|
[6] |
DIVIDER
|
NH
|
| 9. |
9820171
|
[2] |
BRACKET
|
NH
|
| 10. |
86511840
|
[4] |
BOLT,Hex Flng, M6 x 1 x 40mm, Cl 8.8
|
NH
|
| 11. |
353308
|
[4] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 12. |
80701
|
[4] |
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
|
NH
|
| 13. |
29840
|
[4] |
SPRING,Compression, 11.91mm OD x 25.4mm L
|
NH
|
| 14. |
86512444
|
[2] |
CARRIAGE BOLT,M8 x 1.25 x 40mm, Full Thd, Cl 8.8
|
NH
|
| 15. |
27695
|
[2] |
BUSHING,9.53mm ID x 12.83mm OD x 25.4mm L
|
GI
|
| 16. |
80664
|
[2] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 17. |
9804277
|
[2] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 18. |
32379
|
[2] |
SPRING,Extension, 1-1/4" OD x 5-3/8" L
|
PA
|
| 19. |
86633356
|
[2] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 20. |
133095
|
[2] |
SPACER,10.32mm ID x 15.85mm OD x 7.9mm L
|
NH
|
| 21. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 22. |
165109
|
[1] |
DECAL
|
NH
|
