凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (88.100.68[02]) - DIA KIT, NET CONVERSION KIT, DELUXE, YFN188618 AND PRIOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
843 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84605868
|
[1] |
DIA KIT, HARVESTER
|
NH
Net Conversion, Deluxe, Incl 2 - 8
|
| 2. |
84554535
|
[1] |
INSTRUCTION
|
NH
|
| 3. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Net Wrap Assembly, Refer to Figure 68.170.AG
|
| 4. |
84597584
|
[1] |
WRAPPER
|
NH
Assembly
|
| 5. |
84575982
|
[1] |
TWINE BOX
|
NH
Assembly
|
| 6. |
47482694
|
[1] |
WIRE HARNESS
|
NH
BA
|
| 7. |
84339221
|
[1] |
COUNTER
|
NH
Net, Assembly
|
| 8. |
84292754
|
[1] |
CLIP,Cable Tie W/ Fir Tree, 5mm OD x 203mm OAL
|
NH
|
