神钢零件查询(FD6T04) - NISSAN DIESEL ENGINE - LK500 (1/06-12/06) (04-006) - FILTER-PRIMARY Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
641 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VG1640096020 | [1] | FILTER | KOBAssembly Fuel |
| 1. | VG1644499027 | [1] | ELEMENT | KOBELEMENT KIT |
| 5. | VG1644299007 | [1] | COVER COVER | COVER COVER |
| 6. | VG1528499003 | [1] | DRAIN PLUG | KOBPLUG |
| 7. | VG1645499002 | [2] | SPECIAL BOLT | KOBCONNECTOR Superseded by part number: 76550954 |
| 8. | VG1645599002 | [5] | GASKET | KOBPACKING Superseded by part number: VG0135122144 |
| 9. | VG1644599008 | [1] | FLANGE COVER CAP BODY | FLANGE COVER CAP BODY |
| 10. | VG1645299004 | [1] | COCK | KOBCOCK-DRAIN |
| 11. | VG1644699011 | [1] | BOLT BOLT-CENTER | BOLT BOLT-CENTER |
| 12. | VG1644999003 | [1] | SPRING | KOBSPRING |
| 13. | VG1645099000 | [1] | RETAINER | KOBRETAINER |
