纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (02-04) - COOLANT RECOVERY SYSTEM New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
650 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | A171099 | [3] | HOSE CLAMP,13.2mm - 15.4mm | CAS |
| 2. | 87603627 | [1] | RADIATOR HOSE,7.9mm ID x 800mm L, SAE 30R6 | BHBCoolant Recovery; Radiator to Coolant Reservoir |
| 3. | L127093 | [1] | RESERVOIR | CASCoolant Recovery |
| 4. | A184079 | [1] | CAP | CASNon-Vented With Tether Superseded by part number: 440729A1 |
| 5. | 905-8020 | [4] | BOLT,Hex Flg, M8 x 20mm | CAS Superseded by part number: 86511479 |
| 6. | 832-4748 | [5] | FLANGE NUT,M8 x 1.25, Flg, Cl 8 | CAS Superseded by part number: 86050303 |
| 7. | 433784A1 | [1] | HOSE,7.90 mm ID x 445.00 mm, SAE J30 or SAE 20R4 Class D1 | BURCut From L126767, Overflow |
| 8. | 515-23143 | [2] | CLAMP,9/16", Insul, 3/8" Bolt | CAS Superseded by part number: 72187280, 257492 |
