纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (02-03) - RADIATOR/OIL COOLER ASSY New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
994 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 87660637 | [1] | RADIATOR | BURRadiator and Oil Cooler Assembly; Incl. Ref 1 - 5 |
| 1. | 87660641 | [1] | OIL COOLER | BURComponent Parts Not Serviced Separately Superseded by part number: 84279839 |
| 2. | 87710306 | [1] | RADIATOR | BURComponent Parts Not Serviced Separately Superseded by part number: 87735907 |
| 3. | 627-12025 | [4] | BOLT,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd | CAS Superseded by part number: 398792 |
| 4. | 896-11012 | [4] | WASHER,13.5mm ID x 24mm OD x 3mm Thk | CAS Superseded by part number: 86625255 |
| 5. | 87710603 | [2] | BRACKET | BUROil Cooler Mount |
