凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (90.105.BH[05]) - DOOR - LH Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
293 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47513700
|
[1] |
DOOR
|
NH
LH, Incl 16, 17
|
| 2. |
48058532
|
[1] |
|
HINGE
|
| 3. |
47564802
|
[1] |
BRACKET
|
NH
|
| 4. |
47676978
|
[1] |
BRACKET
|
NH
|
| 5. |
47542092
|
[1] |
BRACKET
|
NH
Superseded by part number: 47676986
|
| 6. |
47551513
|
[1] |
SHIELD
|
NH
LH
|
| 7. |
47565567
|
[1] |
SHIELD
|
NH
LH
|
| 8. |
9804258
|
[16] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 9. |
120038
|
[8] |
CARRIAGE BOLT,Rnd Head, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 811-8030
|
| 10. |
9804277
|
[9] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 11. |
84542874
|
[1] |
HANDLE
|
NH
|
| 12. |
86588501
|
[1] |
WASHER,11mm ID x 20mm OD x 2.5mm Thk
|
GI
|
| 13. |
280250
|
[1] |
COTTER PIN,3/32" OD x 3/4" L
|
NH
|
| 14. |
47543772
|
[1] |
BRACKET
|
NH
|
| 15. |
47554123
|
[1] |
PLATE
|
NH
|
| 16. |
47361329
|
[1] |
DANGER DECAL
|
NH
|
| 17. |
84004734
|
[1] |
WARNING DECAL
|
ZED
|
| 18. |
88576
|
[1] |
BOLT,Hex, 1/2" - 13 x 5 1/2", Gr 5
|
NH
|
| 19. |
86521610
|
[1] |
FLANGE NUT,Flg, 1/2"-13
|
NH
|
