纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (02-19) - CYLINDER BLOCK - PLUGS AND PISTONS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
805 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 4895605 | [2] | HEX SOCKET PLUG,M14 x 1.5 | TOR- Assy, Incl. Ref 3 |
| 3. | 4899115 | [1] | O-RING,2.2mm Thk x 11.3mm ID | TOR |
| 4. | 4899009 | [2] | PLUG,M10 x 1.5 | TORIncl. Ref |
| 5. | 4899072 | [1] | O-RING,1.6mm Thk x 8.1mm ID | TOR |
| 6. | 4895392 | [2] | HEX SOCKET PLUG,M18 x 1.5 | TOR- Assy; Incl. Ref 7 |
| 7. | 4895393 | [1] | O-RING,2.2mm Thk x 15.3mm ID | TOR |
| 8. | 4895049 | [2] | DOWEL,M16.05 x 10 | TOR |
| 9. | 4891226 | [12] | TAPPET | LEC57 mm Length; Replaces 4899803 54 mm Length; Used On Some Models |
| 14. | 4896865 | [6] | LUBE OIL NOZZLE | TORLUBE OIL JET NOZZLE Piston Cooling |
| 15. | 4895406 | [2] | EXPANSION PLUG,9.8mm OD | TOR |
| 16. | 4897330 | [1] | HEX SOCKET PLUG,M12 x 1.5 | TORIncl. Ref 17 |
| 17. | 4895610 | [1] | O-RING,2.2mm Thk x 9.3mm ID | TOR |
