纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (02-28) - INTAKE MANIFOLD New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
856 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2854534 | [1] | INLET MANIFOLD | TORAir Intake Superseded by part number: 504114393 |
| 2. | 4895432 | [3] | SCREW | TORFlange, M8 x 70 |
| 3. | 4899039 | [7] | BOLT,Flng, M8 x 1.25 x 25mm, Cl 10.9 | TOR |
| 4. | 2855345 | [1] | HEATER | TORCover, Grid Heater Superseded by part number: 87300128 |
| 5. | 2854701 | [1] | GASKET,0.8mm Thk | TOR Superseded by part number: 504114491 |
| 6. | 2852101 | [6] | FLANGE BOLT,Hex, M6 x 16mm | TOR Superseded by part number: 18137825 |
| 8. | 2830891 | [1] | AIR INTAKE TUBE | TOR |
| 9. | 4899921 | [1] | GASKET,1.2mm Thk | TOR |
| 10. | 4893036 | [1] | PIPE PLUG,3/4"-14 NPTF | TORAlternate for 2854866; If used Superseded by part number: 2854866 |
| 10. | 2854866 | [1] | HEX SOCKET PLUG,3/4"-14 NPTF | TORAlternate for 4893036; If used Superseded by part number: 4893036 |
