神钢零件查询(NE6(T)04) - NISSAN DIESEL ENGINE (1/86-12/98) (08-002) - GENERATOR (INNER PARTS) "NIKKO MAKE 40A & 50A" Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
934 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-38. | VG2310090070 | [1] | GENERATOR | KOBGENERATOR "NIKKO HAKE 40A" |
| 1-38. | VG2310095006 | [1] | ALTERNATOR | KOBGENERATOR "NIKKO MAKE 50A" |
| 1. | VG2310899208 | [1] | ROTOR ASSY ROTOR ASSY | ROTOR ASSY ROTOR ASSY |
| 2. | VG2317299000 | [1] | KEY-WOODRUFF | |
| 3. | VG2311599004 | [1] | COLLAR | |
| 4. | VG2315799112 | [3] | SCREW | |
| 5. | VG2317099006 | [1] | RETAINER | |
| 6. | VG2311699011 | [2] | PACKING | |
| 7. | VG2317099007 | [1] | RETAINER | |
| 8. | VG2312099113 | [1] | BALL BEARING | KOBBEARING-BALL |
| 9. | VG2317099005 | [1] | RETAINER | |
| 10. | VG2311599005 | [1] | COLLAR | |
| 11. | VG2317099008 | [1] | RETAINER | |
| 12. | VG2313199107 | [1] | BOLT | |
| 14-28. | VG2312799404 | [1] | BRACKET ASSY-REAR | |
| 14. | VG2312099114 | [1] | BALL BEARING | KOBBEARING-ROLLER |
| 15. | VG2316699003 | [2] | BUSH-INSULATE | |
| 16. | VG2350099013 | [1] | REGULATOR | KOBREGULATOR ASSY Superseded by part number: 2350099013 |
| 17. | VG2312499010 | [1] | PLATE-TERMINAL | |
| 18. | VG2315799113 | [2] | SCREW | |
| 19. | VG2336999103 | [1] | STOPPER | |
| 20. | VG2312499011 | [1] | PLATE-INSULATE | |
| 21. | VG2315799114 | [1] | SCREW | |
| 22. | VG2312899211 | [1] | BRACKET-REAR | |
| 23. | VG2310999109 | [1] | RECTIFIER | KOBRELTIFIER ASSY Superseded by part number: 2310999109 |
| 24. | VG2336999104 | [1] | STOPPER | |
| 25. | VG2316699002 | [1] | BUSH-INSULATE | |
| 26. | VG2313199108 | [1] | BOLT | |
| 27. | VG2313199109 | [1] | BOLT | |
| 28. | VG2312499012 | [1] | PLATE-TERMINAL | |
| 29. | VG2315799115 | [3] | SCREW | |
| 30. | VG2311199002 | [1] | COIL | KOBCOIL-FIELD Superseded by part number: 2311199002 |
| 31. | VG2310299202 | [1] | STATOR ASSY (FOR 40A) | |
| 31. | VG2310299203 | [1] | STATOR ASSY (FOR 50A) | |
| 32. | VG2311999119 | [1] | BRACKET-FRONT | |
| 33. | VG2313199110 | [3] | BOLT | |
| 34. | VG2337499001 | [1] | FAN | |
| 35. | VG2315199403 | [1] | PULLEY | |
| 36. | VG2315599002 | [1] | WASHER-PLAIN | |
| 37. | VG2315599003 | [1] | WASHER-SPRING | |
| 38. | VG2315299006 | [1] | NUT | |
