神钢零件查询(NE6(T)04) - NISSAN DIESEL ENGINE (1/86-12/98) (08-003) - GENERATOR (INNER PARTS) "HITACHI MAKE 35A" Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
452 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-59. | VG2310095007 | [1] | GENERATOR (FOR 1) | |
| 1-59. | VG2310095010 | [1] | GENERATOR (FOR 2), NOT FOR SALE INDIVIDUALLY | |
| 1-1. | VG2310899119 | [1] | ROTOR | KOBROTOR ASSY |
| 7. | VG2319590000 | [1] | KEY KEY | KEY KEY |
| 8.9. | VG2311799006 | [1] | RETAINER PROTECTOR | RETAINER PROTECTOR |
| 9. | VG2311699004 | [1] | PACKING | KOBPACKING |
| 10. | VG2312099104 | [1] | BALL BEARING | KOBBEARING-BALL |
| 11. | VG2312099105 | [1] | BALL BEARING | KOBBEARING-BALL |
| 12. | VG2311199000 | [1] | FIELD ATTACHMENT | KOBCOIL-FIELD |
| 1 3. | VG2310299112 | [1] | STATOR | KOBSTATOR ASSY |
| 14-29. | VG2312799406 | [1] | COVER ASSY-REAR (INC.KEY NO.53-59) FOR 1 | |
| 14-29. | VG2312799409 | [1] | COVER ASSY-REAR (INC.KEY NO.53-59) FOR 2, NOT FOR SALE INDIVIDUALLY | |
| 14. | VG2312799305 | [1] | COVER-REAR | |
| 16. | VG2314699016 | [1] | BOLT-TERMINAL | |
| 17.18. | VG23136Z9002 | [1] | DIODE | KOBDIODE ASSY (FOR 2), NOT FOR SALE INDIVIDUALLY |
| 17.18. | VG2313799009 | [1] | DIODE ASSY (FOR 1) | |
| 17. | VG2311299000 | [3] | SUB-DIODE DIODE ASSY-SUB | SUB-DIODE DIODE ASSY-SUB |
| 19. | VG2314790007 | [2] | BOLT BOLT-TERMINAL | BOLT BOLT-TERMINAL |
| 20. | VG2314790007 | [1] | BOLT COVER-TERMINAL (FOR 1) | BOLT COVER-TERMINAL (FOR 1) |
| 20. | VG2314899000 | [1] | COVER COVER-TERMINAL (FOR 2) | COVER COVER-TERMINAL (FOR 2) |
| 21. | VG2310799006 | [1] | COVER | |
| 22. | VG2317499001 | [1] | CAP-GREASE | |
| 23. | VG2313999002 | [1] | O-RING | KOBO RING |
| 28.29. | VG2350099014 | [1] | REGURATOR ASSY (FOR 1) | |
| 28.29. | VG2350099016 | [1] | REGURATOR ASSY (FOR 2), NOT FOR SALE INDIVIDUALLY | |
| 28. | VG2350099008 | [1] | VOLTAGE REGULATOR | KOBIC REGURATOR Superseded by part number: 76605796 |
| 29. | VG2316599208 | [1] | WIRE ASSY-READ | |
| 39-41. | VG2311999111 | [1] | COVER ASSY FRONT | |
| 41. | VG2312199001 | [1] | PACKING | KOBPACKING |
| 45. | VG2315199405 | [1] | PULLEY | |
| 46. | VG2316199001 | [1] | NUT | KOBNUT ASSY |
| 47. | VG2313199019 | [4] | BOLT-THROUH | |
