凯斯零件查询(RBX341) - CASE IH ROUND BALER (9/02-12/05) (06.01[01]) - FRONT LIGHTS AND REFLECTORS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
860 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
80799266
|
[2] |
LAMP REFLECTOR
|
ZED
White Superseded by part number: 799266
|
| 2. |
80435895
|
[4] |
LAMP REFLECTOR
|
ZED
Yellow Superseded by part number: 435895
|
| 3. |
89503930
|
[1] |
CLAMP
|
ZED
RP16 Superseded by part number: 84818443
|
| 3. |
89503932
|
[1] |
CLAMP
|
ZED
RP25 Superseded by part number: 84818445
|
| 3. |
89503929
|
[1] |
CLAMP
|
ZED
RP13 Superseded by part number: 84818442
|
| 4. |
84005019
|
[2] |
GROMMET
|
PLO
, Serial Range: -C639
|
| 4. |
84819160
|
[2] |
GROMMET
|
PLO
, Start Serial: D640
|
| 5. |
84822316
|
[1] |
PROFILE
|
PLO
, Serial Range: -C667 Superseded by part number: 84820688
|
| 5. |
84820688
|
[1] |
PROFILE
|
PLO
, Start Serial: D668
|
| 6. |
80336483
|
[2] |
LAMP, TAIL
|
ZED
LIGHT, TAIL Superseded by part number: 336483
|
| 7. |
80470016
|
[2] |
BULB
|
ZED
12V-10W Superseded by part number: E35556
|
| 8. |
84818613
|
[1] |
WIRE HARNESS
|
PLO
, Serial Range: -C639
|
| 8. |
84447454
|
[1] |
WIRE HARNESS
|
PLO
, Start Serial: D640
|
| 9. |
80323597
|
[4] |
STRAP
|
ZED
Superseded by part number: 14560287
|
