凯斯零件查询(RBX341) - CASE IH ROUND BALER (9/02-12/05) (06.02[01]) - REAR LIGHTS AND REFLECTORS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
788 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
80120099
|
[6] |
BOLT,Hex, M6 x 16, 8.8
|
ZED
Superseded by part number: 86508568
|
| 2. |
84005685
|
[1] |
STRIP-GASKET
|
ZED
|
| 3. |
80322357
|
[6] |
LOCK WASHER,Belleville, M6
|
ZED
6MM Superseded by part number: 322357
|
| 4. |
15896221
|
[6] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 5. |
89503931
|
[5] |
CLAMP
|
ZED
Superseded by part number: 84818444
|
| 6. |
80418870
|
[1] |
BULB
|
ZED
12V-10W Superseded by part number: 14149590
|
| 7. |
84320919
|
[1] |
SUPPORT
|
PLO
|
| 8. |
80398877
|
[1] |
BULB
|
ZED
12V-21W Superseded by part number: 14148190
|
| 9. |
84037093
|
[1] |
TAIL LAMP,12V, 21W, Amber/Red
|
ZED
|
| 10. |
80322358
|
[4] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 11. |
80378243
|
[4] |
WASHER
|
ZED
8MM Superseded by part number: 378243
|
| 12. |
120104
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 13. |
84037090
|
[1] |
TAIL LAMP,12V, 21W, Amber/Red
|
ZED
|
| 14. |
80746294
|
[2] |
LAMP REFLECTOR
|
ZED
|
| 15. |
80100012
|
[1] |
NUT
|
ZED
M4 Superseded by part number: 57121
|
| 16. |
80322355
|
[1] |
WASHER
|
ZED
4MM Superseded by part number: 322355
|
| 17. |
80120007
|
[4] |
SCREW
|
ZED
M4x16 Superseded by part number: 13272214
|
| 18. |
84429173
|
[1] |
SUPPORT
|
PLO
|
| 19. |
84447467
|
[1] |
WIRE HARNESS
|
PLO
, Start Serial: D640
|
| 20. |
80398224
|
[1] |
POWER SOCKET
|
ZED
, Start Serial: D640 Superseded by part number: 83959716
|
| 21. |
84446946
|
[1] |
SUPPORT
|
PLO
, Start Serial: D640
|
| 22. |
80338844
|
[1] |
GROMMET
|
ZED
, Start Serial: D640 Superseded by part number: 338844
|
