| 1. | 201-402 | [1] | TEE,13/16"-18 x 3/4"-16 Br, ORFS | IHIncl. Ref 2, 2A Superseded by part number: 87016878 |
| 2. | 238-6014 | [2] | O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 9992298 |
| 2A. | 237-6008 | [1] | O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro | CASBoss end Superseded by part number: 128825 |
| 3. | 87564922 | [1] | HOSE ASSY. | BUR1100 mm (43-5/16 in); Rear of Motors, Crossover |
| 4. | 201-147 | [2] | REDUCER,1 3/16"-12 Male x 1 7/16"-12 Fem, ORFS | CASIncl. Ref 5, 6 |
| 5. | 238-6018 | [1] | O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 9991976 |
| 6. | 238-6021 | [1] | O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro | CAS1 in Face Seal End Superseded by part number: 87473574 |
| 7. | 87313556 | [2] | HYDROSTATIC MOTOR | BURHydrostatic; Use With Loctite 767 On Shafts; See Figures 06-10, 06-11 |
| . . | 87313556R | [2] | REMAN-HYD MOTOR | BURD150B - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) |
| . . | 87313556C | [1] | CORE-MOTOR HYDRAULIC | BURReturn Number |
| 8. | 627-16055 | [8] | BOLT,Hex, M16 x 2 x 55mm, Cl 10.9, Full Thd | CASUse with Loctite 243 Superseded by part number: 86900235 |
| 9. | 892-11016 | [8] | LOCK WASHER,16.4mm ID x 27.4mm OD x 5mm Thk | CAS Superseded by part number: 87016618 |
| 10. | 87710995 | [2] | O-RING,0.139" Thk x 6.984" ID, -262, Cl 5, 75 Duro | BURO-Ring |
| 11. | 87660633 | [1] | HOSE ASSY. | BUR785 mm (30-15/16 in); Rear Pump To Right-Hand Motor; Upper |
| 12. | 87564911 | [1] | HOSE ASSY.,25.4mm ID x 880mm L, SAE 100R15 | BUR880 mm (34-11/16 in); Front Pump To Left-Hand Motor; Lower |
| 13. | 87564913 | [1] | HOSE ASSY. | BUR1100 mm (43-5/16 in); Front Pump To Left-Hand Motor; Upper |
| 14. | 87660635 | [1] | HOSE ASSY.,25.4mm ID x 1040mm L, SAE 100R15 | BUR1040 mm (41 in); Rear Pump To Right-Hand Motor; Lower |
| 15. | 238-6220 | [4] | O-RING,0.139" Thk x 1.359" ID, -220, Cl 6, 90 Duro | CASO-Ring Superseded by part number: 70925934 |
| 16. | 76044748 | [8] | FLANGE | LECSplit Flange Superseded by part number: 71444029 |
| 17. | 11116021 | [16] | SCREW,Hex, M14 x 45mm, Cl 8.8, Full Thd | MKTBOLT Superseded by part number: 87015765 |
| 18. | 87016615 | [16] | WASHER,15.3mm ID x 28.5mm OD x 3mm Thk | RAC |
| 19. | 201-104 | [2] | HYD CONNECTOR,1-3/16" - 12 ORFS x 1-1/16" - 12 ORB | CASIncl. Ref 20, 21 Superseded by part number: 87393627 |
| 20. | 237-6012 | [2] | O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro | CASBoss End Superseded by part number: 72186120, 167266, 79051113 |
| 22. | 201-419 | [1] | TEE,1 3/16"-12 ORFS x 1 3/16"-18 Sw Br | CASIncl. Ref 23 |
| 24. | 87673125 | [1] | HOSE ASSY. | BURHOSE ASSY., 910 mm (35-7/8 in); Case Drain Crossover |
| 25. | 87673123 | [1] | HOSE ASSY. | BURHose Assy; 1187 mm (46-3/4 in); Case Drain To Tank |
| 29. | 87564923 | [1] | HOSE ASSY. | BUR880 mm (34-11/16 in); Left-Hand Motor to Bypass Valve |
| 30. | 201-305 | [1] | ELBOW,90º, 13/16"-16 x 3/4"-16 Adj, ORFS | CASIncl. Ref 31, 32 Superseded by part number: 9992307 |
| 33. | 238-6219 | [4] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | CAS Superseded by part number: 86529541 |
| 34. | 9628065 | [16] | SCREW,Hex, M12 x 1.75 x 45mm, Cl 8.8 | NH |
| 35. | 86625255 | [16] | WASHER,13.3mm ID x 24.5mm OD x 3mm Thk | GI |
| 36. | 86980732 | [8] | CLAMP | GI |
