神钢零件查询(NE6(T)04) - NISSAN DIESEL ENGINE (1/86-12/98) (08-007) - MOTOR STARTING (INNER PARTS) "HITACHI MAKE" Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
537 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-24. | VG2330095009 | [1] | MOTOR-STARTING | |
| 1-3. | VG2331099205 | [1] | ARMATURE ASSY | |
| 2. | VG23383Z9002 | [1] | BEARING BALL | BEARING BALL |
| 3. | VG23383Z9003 | [1] | AIR CLEANER BEARING-BALL | AIR CLEANER BEARING-BALL |
| 4. | VG2337299010 | [1] | WASHER KIT-PINION | |
| 5. | VG2336999101 | [1] | STOPPER SET-PINION | |
| 7.8. | VG2330699209 | [1] | COIL ASSY-FIELD | |
| 8. | VG2333199017 | [2] | BRUSH (+) | |
| 9. | VG2333799206 | [1] | COVER ASSY-REAR | |
| 10-12. | VG2333099115 | [1] | HOLDER ASSY-BRUSH | |
| 11. | VG2333199017 | [2] | BRUSH (-) | |
| 12. | VG23333Z9001 | [4] | SPRING | KOB Superseded by part number: 76605819 |
| 13. | VG2338399205 | [1] | BEARING-CENTER | |
| 14. | VG2332699011 | [1] | PLATE-CENTER | |
| 15.16. | VG2334899012 | [1] | SHAFT ASSY-GEAR | |
| 16. | VG23341T9000 | [1] | BEARING BALL | BEARING BALL |
| 17. | VG2331399210 | [1] | PINION ASSY | |
| 18. | VG2334399209 | [1] | SWITCH ASSY-MAGNETIC | |
| 20.21. | VG2331899300 | [1] | CASE ASSY-GEAR | |
| 21. | VG2331961503 | [1] | METAL-GEAR CASE | |
| 22. | VG2332261502 | [1] | LEVER | KOBSET-SHIFT Superseded by part number: 76605830 |
| 23. | VG2334199019 | [1] | COVER KIT-DUST | |
| 24. | VG23340J5500 | [2] | BOLT-THROUGH | |
