凯斯零件查询(RBX341) - CASE IH ROUND BALER (9/02-12/05) (06.04[01]) - WIRE HARNESS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
182 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84025876
|
[1] |
SUPPORT
|
POL
Superseded by part number: 787868
|
| 2. |
80636665
|
[1] |
LOCK WASHER
|
ZED
Superseded by part number: 84607513
|
| 3. |
80636666
|
[1] |
NUT
|
ZED
Superseded by part number: 459329C1
|
| 4. |
80767456
|
[1] |
PLUG
|
PLO
Superseded by part number: 245041C1
|
| 5. |
617887
|
[1] |
HOOK
|
NH
|
| 6. |
80120032
|
[1] |
BOLT
|
ZED
Superseded by part number: 9706703
|
| 7. |
80431351
|
[1] |
CLAMP
|
ZED
Superseded by part number: 431351
|
| 8. |
80140015
|
[1] |
WASHER
|
ZED
Superseded by part number: 86588450
|
| 9. |
80140044
|
[1] |
WASHER
|
ZED
Superseded by part number: 322357
|
| 10. |
15896221
|
[1] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 11. |
86525834
|
[1] |
WIRE HARNESS
|
PLO
, Serial Range: (12-20)
|
| 12. |
9619682
|
[1] |
BUSHING
|
NH
|
| 13. |
850072
|
[1] |
COLLAR CLAMP
|
NH
Superseded by part number: 445525
|
| 14. |
9622758
|
[1] |
COUPLING RING
|
NH
|
| 15. |
9609190
|
[1] |
HYD CONNECTOR
|
NH
Superseded by part number: 87707146
|
| 16. |
9609191
|
[1] |
MULTIPOLE CONNECTOR,Female, 9 Pole
|
NH
Superseded by part number: 291658A1
|
| 17. |
80900363
|
[1] |
TERMINAL
|
ZED
Superseded by part number: 87695607
|
| 18. |
900364
|
[1] |
TERMINAL CONNECTOR
|
NH
|
| 19. |
86534877
|
[1] |
POWER SOCKET
|
BRE
3 PIN Superseded by part number: 82013449
|
| 20. |
86534878
|
[1] |
PLUG
|
BRE
|
